DLK-116
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
DOOR LOCK ACTUATOR
2. Check continuity between BCM connector M20 terminals 68 and
ground.
Is the inspection result normal?
YES >> Harness is OK. Refer to DLK-116, "BACK DOOR : Component Inspection".
NO >> Repair or replace harness.
BACK DOOR : Component InspectionINFOID:0000000001507410
1.CHECK TRUNK LAMP SWITCH
Momentarilly, connect battery power supply to back door lock
assembly terminals and check for actuator operation.
Is the inspection result normal?
YES >> Replace BCM. Refer to XX-XX, "*****".
NO >> Replace back door lock assembly.
Terminals Continuity
68 Ground No
ALKIA0782ZZ
ALKIA0779ZZ
Te r m i n a l
Back door condition
Back door lock assembly (actuator)
1 BAT (+) 2 BAT (-) Actuator operates
Page 706 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TRUNK LID OPENER ACTUATOR
DLK-117
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID OPENER ACTUATOR
DescriptionINFOID:0000000001507345
Performs trunk l NISSAN TIIDA 2007 Service Repair Manual TRUNK LID OPENER ACTUATOR
DLK-117
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID OPENER ACTUATOR
DescriptionINFOID:0000000001507345
Performs trunk l](/manual-img/5/57395/w960_57395-705.png)
TRUNK LID OPENER ACTUATOR
DLK-117
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID OPENER ACTUATOR
DescriptionINFOID:0000000001507345
Performs trunk lid open with signal from BCM.
Component Function CheckINFOID:0000000001507346
1.CHECK FUNCTION
1. Perform Active Test TRUNK/GLASS HATCH with CONSULT-III.
2. Touch “OPEN” and check that trunk lid opens.
Is the inspection result normal?
YES >> Trunk lid opener actuator is OK.
NO >> Refer to DLK-117, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001507347
1.CHECK OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Ensure door lock system is unlocked.
3. Check voltage between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> GO TO 2
2.CHECK TRUNK LID OPENER ACTUATOR CIRCUIT
1. Disconnect BCM and trunk lamp switch and trunk release solenoid connectors.
2. Check continuity between BCM connector (A) M20 terminal 68
and trunk lamp switch and trunk release solenoid connector (B)
B66 terminal 2.
ALKIA0765ZZ
Te r m i n a l s
Condition of trunk lid open-
er switchVoltage (V)
(Approx.) (+)
(–)
BCM connector Terminal
M20 68 Ground ON 0 → Battery voltage → 0
ALKIA0766ZZ
Page 707 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-118
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
TRUNK LID OPENER ACTUATOR
3. Check continuity between BCM connector (A) M20 terminal 68 and ground.
Is the inspection result normal?
YES NISSAN TIIDA 2007 Service Repair Manual DLK-118
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
TRUNK LID OPENER ACTUATOR
3. Check continuity between BCM connector (A) M20 terminal 68 and ground.
Is the inspection result normal?
YES](/manual-img/5/57395/w960_57395-706.png)
DLK-118
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
TRUNK LID OPENER ACTUATOR
3. Check continuity between BCM connector (A) M20 terminal 68 and ground.
Is the inspection result normal?
YES >> Refer to DLK-118, "Component Inspection".
NO >> Repair or replace harness.
3.CHECK TRUNK LID OPENER ACTUATOR GROUND CIRCUIT
Check continuity between trunk lamp switch and trunk release sole-
noid connector and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace trunk lamp switch and trunk release solenoid ground circuit.
4.CHECK INTERMITTENT INCIDENT
Refer to XX-XX, "*****"
.
>> INSPECTION END.
Component InspectionINFOID:0000000001507351
1.CHECK TRUNK LAMP SWITCH
Momentarilly, connect battery power supply to trunk lamp switch and
trunk release solenoid terminals and check for solenoid operation.
BCM connector Terminaltrunk lamp switch and trunk re-
lease solenoid connectorTerminal Continuity
M20 68 B66 2 Yes
BCM connector Terminal Continuity
M20 68 Ground No
ALKIA0763ZZ
Trunk lamp switch and trunk release
solenoid connectorTe r m i n a l
GroundContinuity
B66 1 Yes
ALKIA0767ZZ
Page 708 of 5883
TRUNK LID OPENER ACTUATOR
DLK-119
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> INSPECTION END.
NO >> Replace trunk lamp switch and trunk release solenoid.
Te r m i n a l
Trunk condition
Trunk lamp switch and trunk release solenoid
1 BAT (-) 2 BAT (+) Solenoid operates
Page 709 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-120
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
INSIDE KEY ANTENNA
INSIDE KEY ANTENNA
INSTRUMENT CENTER
INSTRUMENT CENTER : DescriptionINFOID:0000000001396601
Detects whether Intellige NISSAN TIIDA 2007 Service Repair Manual DLK-120
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
INSIDE KEY ANTENNA
INSIDE KEY ANTENNA
INSTRUMENT CENTER
INSTRUMENT CENTER : DescriptionINFOID:0000000001396601
Detects whether Intellige](/manual-img/5/57395/w960_57395-708.png)
DLK-120
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
INSIDE KEY ANTENNA
INSIDE KEY ANTENNA
INSTRUMENT CENTER
INSTRUMENT CENTER : DescriptionINFOID:0000000001396601
Detects whether Intelligent Key is inside the vehicle.
INSTRUMENT CENTER : Component Function CheckINFOID:0000000001396602
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL
With CONSULT-III
1. Check “ANTENNA” in “Active Test” mode with CONSULT-III.
2. Touch “ROOM ANT 2”.
3. When Intelligent Key is in inside key antenna (instrument panel) detection area, hazard lamp flashes.
Is the inspection result normal?
YES >> Inside key antenna (instrument panel) is OK.
NO >> Refer to DLK-120, "
INSTRUMENT CENTER : Diagnosis Procedure".
INSTRUMENT CENTER : Diagnosis ProcedureINFOID:0000000001396603
1.CHECK INSIDE KEY ANTENNA INPUT SIGNAL 1
1. Turn ignition switch OFF.
2. Check signal between Intelligent Key unit connector and ground
with oscilloscope.
Test Item Inside Antenna
ANTENNA :ROOM ANT 2 Inside key antenna (instrument panel)
ALKIA0783ZZ
Page 710 of 5883
INSIDE KEY ANTENNA
DLK-121
< COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK INSIDE KEY ANTENNA CIRCUIT
1. Disconnect Intelligent Key unit connector and inside key antenna (instrument panel) connector.
2. Check continuity between Intelligent Key unit connector (A) M52
terminals 15, 16 and instrument panel antenna connector (B)
M10 terminals 1, 2.
Te r m i n a l s
