BRC-184
< REMOVAL AND INSTALLATION >[ESP/TCS/ABS]
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
ACTUATOR AND ELECTRIC UNIT (ASSEMBLY)
Removal and InstallationINFOID:0000000001691453
REMOVAL
1. Disconnect ABS actuator and electric unit (control unit) connector.
2. Loosen brake tube flare nuts, then remove brake tubes from ABS actuator and electric unit (control unit).
3. Remove ABS actuator and electric unit (control unit) mounting nuts.
4. Remove ABS actuator and electric unit (control unit) from vehicle.
CAUTION:
Be careful of the following when removing ABS actuator and electric unit (control unit).
If the part number on the part number label (pasted on actuator upper surface) is the same, ABS
actuator and electric unit (control unit) cannot be used on another vehicle.
If it is used on another vehicle, ABS warning lamp, SLIP indicator lamp and ESP OFF indicator lamp
may turn ON or ESP/TCS/ABS may not operate normally.
When replacing ABS actuator and electric unit (control unit), must use new service parts.
Before servicing, disconnect battery cables.
To remove brake tube, use a flare nut wrench to prevent flare nuts and brake tube from being dam-
aged. To install, use a flare nut torque wrench (commercial service tool) and tighten to the specified
torque.
Do not apply excessive impact to actuator, such as dropping it.
Do not remove and install ABS actuator and electric unit (control unit) by holding harness.
INSTALLATION
To install, follow procedure for removal in reverse order.
CAUTION:
Be careful of the following when installing ABS actuator and electric unit (control unit).
Tighten the mounting bolts and nuts to the specified torque.
After the work, bleed air from brake piping. Refer to BR-8, "
Bleeding Brake System".
After installing vehicle harness connector in the actuator, make sure connector is securely locked.
MFIA0015E
Page 418 of 5883
YAW RATE/SIDE G SENSOR
BRC-185
< REMOVAL AND INSTALLATION >[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
YAW RATE/SIDE G SENSOR
Removal and InstallationINFOID:0000000001691454
REMOVAL
1. Remove center console. Refer to IP-10, "Component Parts".
2. Disconnect yaw rate/side G-sensor harness connector.
3. Remove yaw rate/side G-sensor mounting bolts. Then remove yaw rate/side G-sensor from vehicle.
CAUTION:
Do not drop or strike yaw rate/side G-sensor, because it has little endurance to impact.
Do not use power tool etc., because yaw rate/side G-sensor is weak for the impact.
INSTALLATION
To install, follow procedure for removal in reverse order.
CAUTION:
Do not drop or strike yaw rate/side G-sensor, because it has little endurance to impact.
MFIA0016E
Page 419 of 5883
BRC-186
< REMOVAL AND INSTALLATION >[ESP/TCS/ABS]
STEERING ANGLE SENSOR
STEERING ANGLE SENSOR
Removal and InstallationINFOID:0000000001691455
For removal and installation of steering angle sensor, refer to SR-7, "Removal and Installation".
Page 420 of 5883
