NISSAN TIIDA 2007 Service Repair Manual EC-1268
< SYMPTOM DIAGNOSIS >[K9K]
NO OR VERY LITTLE ACCELERATION, INCREASE IN ENGINE SPEED
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace.
10.CHECK CATALYTIC CONVERTER
Is t

EC-1268
< SYMPTOM DIAGNOSIS >[K9K]
NO OR VERY LITTLE ACCELERATION, INCREASE IN ENGINE SPEED
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace.
10.CHECK CATALYTIC CONVERTER
Is the catalytic converter clogged or deteriorated?
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace.
11 .CHECK CAN COMMUNICATION
Perform trouble diagnosis on the CAN communication line using CONSULT-III. Refer to LAN-33, "
CAN Com-
munication Signal Chart".
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair or replace harness or connector.
12.CHECK LOW PRESSURE CIRCUIT
Perform the TEST 1: LOW PRESSURE CIRCUIT CHECK. Refer to EC-1043, "
BASIC INSPECTION : Special
Repair Requirement (TEST 1: Low Pressure Fuel Supply System Check)".
>> GO TO 13.
13.CHECK INTERNAL FUEL TRANSFER PUMP
Perform the TEST 2: INTERNAL FUEL TRANSFER PUMP CHECK. Refer to EC-1044, "
BASIC INSPECTION
: Special Repair Requirement (TEST 2: Internal Fuel Transfer Pump Check)".
>> GO TO 14.
14.CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)
Perform the TEST 3: HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE). Refer to EC-1044,
"BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump (Pressure Control
Valve) Check]".
>> GO TO 15.
15.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE). Refer to EC-
1045, "BASIC INSPECTION : Special Repair Requirement [TEST 4: High Pressure Supply Pump (Volumetric
Control Valve) Check]".
>> GO TO 16.
16.CHECK RAIL HIGH PRESSURE CONTROL CIRCUIT
Perform the TEST 5: RAIL HIGH PRESSURE CONTROL CIRCUIT CHECK. Refer to EC-1048, "
BASIC
INSPECTION : Special Repair Requirement (TEST 5: Rail High Pressure Regulation Check)".
>> GO TO 17.
17.CHECK MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN
Perform the TEST 6: MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN. Refer to EC-1052,
"BASIC INSPECTION : Special Repair Requirement (TEST 6: Major Leak in Fuel Injectors/Fuel Injectors
Open)".
>> GO TO 18.
18.CHECK INCORRECT FUEL INJECTION QUANTITY

Page 2618 of 5883

NISSAN TIIDA 2007 Service Repair Manual NO OR VERY LITTLE ACCELERATION, INCREASE IN ENGINE SPEED
EC-1269
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Perform the TEST 7: INCORRECT FUEL INJECTION QUANTITY. Refer to EC-1053, "BA

Page 2619 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1270
< SYMPTOM DIAGNOSIS >[K9K]
ENGINE BUCKING
ENGINE BUCKING
DescriptionINFOID:0000000001162715
CHART 9: ENGINE BUCKING
Diagnosis ProcedureINFOID:0000000001162716
1.CHECK ECM POWER SUPPLY AND GROU

Page 2620 of 5883

NISSAN TIIDA 2007 Service Repair Manual ENGINE BUCKING
EC-1271
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
YES >> GO TO 9.
NO >> Repair or replace.
9.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor. Refer to EC-1125, "

ENGINE BUCKING
EC-1271
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
YES >> GO TO 9.
NO >> Repair or replace.
9.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor. Refer to EC-1125, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace.
10.CHECK LOW PRESSURE CIRCUIT
Perform the TEST 1: LOW PRESSURE CIRCUIT CHECK. Refer to EC-1043, "
BASIC INSPECTION : Special
Repair Requirement (TEST 1: Low Pressure Fuel Supply System Check)".
>> GO TO 11.
11 .CHECK INTERNAL FUEL TRANSFER PUMP
Perform the TEST 2: INTERNAL FUEL TRANSFER PUMP CHECK. Refer to EC-1044, "
BASIC INSPECTION
: Special Repair Requirement (TEST 2: Internal Fuel Transfer Pump Check)".
>> GO TO 12.
12.CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)
Perform the TEST 3: HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE). Refer to EC-1044,
"BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump (Pressure Control
Valve) Check]".
>> GO TO 13.
13.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE). Refer to EC-
1045, "BASIC INSPECTION : Special Repair Requirement [TEST 4: High Pressure Supply Pump (Volumetric
Control Valve) Check]".
>> GO TO 14.
14.CHECK RAIL HIGH PRESSURE CONTROL CIRCUIT
Perform the TEST 5: RAIL HIGH PRESSURE CONTROL CIRCUIT CHECK. Refer to EC-1048, "
BASIC
INSPECTION : Special Repair Requirement (TEST 5: Rail High Pressure Regulation Check)".
>> GO TO 15.
15.CHECK MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN
Perform the TEST 6: MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN. Refer to EC-1052,
"BASIC INSPECTION : Special Repair Requirement (TEST 6: Major Leak in Fuel Injectors/Fuel Injectors
Open)".
>> GO TO 16.
16.CHECK INCORRECT FUEL INJECTION QUANTITY
Perform the TEST 7: INCORRECT FUEL INJECTION QUANTITY. Refer to EC-1053, "
BASIC INSPECTION :
Special Repair Requirement (TEST 7: Incorrect Fuel Injection Quantity)".
>>INSPECTION END

Page 2621 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1272
< SYMPTOM DIAGNOSIS >[K9K]
ERRATIC ACCELERATION
ERRATIC ACCELERATION
DescriptionINFOID:0000000001162717
CHART 10: Erratic acceleration
Diagnosis ProcedureINFOID:0000000001162718
1.CHECK ECM PO

Page 2622 of 5883

NISSAN TIIDA 2007 Service Repair Manual ERRATIC ACCELERATION
EC-1273
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE). Refer to EC-
1045, "BASIC INSPECTION :

Page 2623 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1274
< SYMPTOM DIAGNOSIS >[K9K]
NO ENGINE BRAKING
NO ENGINE BRAKING
DescriptionINFOID:0000000001162719
CHART 11: NO ENGINE BRAKING
Diagnosis ProcedureINFOID:0000000001162720
1.CHECK ECM POWER SUPPL

Page 2624 of 5883

NISSAN TIIDA 2007 Service Repair Manual LOSS OF POWER
EC-1275
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
LOSS OF POWER
DescriptionINFOID:0000000001162721
CHART 12: LOSS OF POWER
Diagnosis ProcedureINFOID:0000000001162722
1.C
