PREPARATION
TM-671
< PREPARATION >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Drift
a: 17 mm (0.67 in) dia. Installing bushing
Installing shifter lever oil seal
Installing selector lever oil seal
Drift
a: 35 mm (1.38 in) dia.
b: 25 mm (0.98 in) dia.Installing input shaft front bearing
Drift
a: 24 mm (0.94 in) dia.Removing input shaft rear bearing
Drift
a: 43 mm (1.69 in) dia. Removing differential side bearing inner
race (transaxle case side)
Installing input shaft rear bearing
Drift
a: 45 mm (1.77 in) dia.
b: 39 mm (1.54 in) dia.Installing differential side bearing inner race
(clutch housing side)
Drift
a: 52 mm (2.05 in) dia.
b: 45 mm (1.77 in) dia.Installing differential side bearing inner race
(transaxle case side) Tool nameDescription
S-NT063
S-NT065
PCIB1779E
NT109
S-NT474
S-NT474
Page 5618 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-672
< ON-VEHICLE MAINTENANCE >[6MT: RS6F94R]
GEAR OIL
ON-VEHICLE MAINTENANCE
GEAR OIL
Exploded ViewINFOID:0000000001381632
Refer to TM-635, "Exploded View".
DrainingINFOID:0000000001381633
1. Start NISSAN TIIDA 2007 Service Repair Manual TM-672
< ON-VEHICLE MAINTENANCE >[6MT: RS6F94R]
GEAR OIL
ON-VEHICLE MAINTENANCE
GEAR OIL
Exploded ViewINFOID:0000000001381632
Refer to TM-635, "Exploded View".
DrainingINFOID:0000000001381633
1. Start](/manual-img/5/57395/w960_57395-5617.png)
TM-672
< ON-VEHICLE MAINTENANCE >[6MT: RS6F94R]
GEAR OIL
ON-VEHICLE MAINTENANCE
GEAR OIL
Exploded ViewINFOID:0000000001381632
Refer to TM-635, "Exploded View".
DrainingINFOID:0000000001381633
1. Start engine and let it run to warm up transaxle.
2. Stop engine. Remove drain plug (1) and then drain oil.
3. Set a new gasket on drain plug (1) and install it to transaxle and
tighten drain plug to the specified torque. Refer to TM-683,
"Exploded View".
CAUTION:
Do not reuse gasket.
RefillingINFOID:0000000001381634
1. Remove filler plug (1). Fill with new oil until oil level reaches the
specified limit near filler plug hole as shown.
2. After refilling oil, check oil level.
3. Set a new gasket on filler plug (1), then install it to transaxle and
tighten to the specified torque. Refer to TM-683, "
Exploded
View".
CAUTION:
Do not reuse gasket.
InspectionINFOID:0000000001381635
LEAKAGE
Make sure that oil is not leaking from transaxle or around it.
LEVEL
1. Remove filler plug (1) and check oil level at filler plug hole as
shown.
CAUTION:
Do not start engine while checking oil level.
2. Set a new gasket on filler plug (1) and install it to the transaxle
case.
CAUTION:
Do not reuse gasket.
3. Tighten filler plug to the specified torque. Refer to TM-683,
"Exploded View".
SCIA7622E
Oil grade and capacity : Refer to MA-19, "Fluids and
Lubricants".
SCIA7623E
SCIA7623E
Page 5619 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SIDE OIL SEAL
TM-673
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ON-VEHICLE REPAIR
SIDE OIL SEAL
Exploded ViewINFOID:0000000001381636
Refer to TM-635, "Exploded View".
Removal NISSAN TIIDA 2007 Service Repair Manual SIDE OIL SEAL
TM-673
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ON-VEHICLE REPAIR
SIDE OIL SEAL
Exploded ViewINFOID:0000000001381636
Refer to TM-635, "Exploded View".
Removal](/manual-img/5/57395/w960_57395-5618.png)
SIDE OIL SEAL
TM-673
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ON-VEHICLE REPAIR
SIDE OIL SEAL
Exploded ViewINFOID:0000000001381636
Refer to TM-635, "Exploded View".
Removal and InstallationINFOID:0000000001381637
REMOVAL
1. Remove front drive shafts. Refer to FAX-10, "Removal and Installation (Left Side)" and FA X - 11 , "Removal
and Installation (Right Side)".
2. Remove differential side oil seals (1) using a suitable tool.
CAUTION:
Do not damage transaxle case and clutch housing.
INSTALLATION
Installation is in the reverse order of removal.
Install differential side oil seals (1) to transaxle case side (B) and
clutch housing side (C) using Tool (A).
CAUTION:
Do not reuse differential side oil seal.
When installing, never incline differential side oil seal.
Do not damage clutch housing and transaxle case.
Check oil level and oil leakage after installation. Refer to TM-628,
"Inspection".
SCIA7625E
Tool number : KV38100300
Dimension “L
1” : 1.2 - 1.8 mm (0.047 - 0.071 in)
Dimension “L
2” : 2.7 - 3.3 mm (0.106 - 0.130 in)
JPDIC0120ZZ
Page 5620 of 5883
TM-674
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
CONTROL LINKAGE
CONTROL LINKAGE
Exploded ViewINFOID:0000000001381638
Removal and InstallationINFOID:0000000001381639
REMOVAL
1. Remove the air cleaner and air duct. Refer to EM-154, "Removal and Installation" (MR18DE) or EM-269,
"Removal and Installation" (K9K).
2. Remove the battery. Refer to PG-6, "
Removal and Installation".
1. Bracket 2. Shift cable 3. Selector lever
4. Shifter lever 5. Tapping bolt 6. Cable mounting bracket
7. Select cable 8. Grommet 9. Control device assembly
10. Control lever 11. Control lever knob
JPDIC0058GB
Page 5621 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CONTROL LINKAGE
TM-675
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Disconnect connectors (A) and then remove bracket (1).
4. While pressing the lock of the select cable in t NISSAN TIIDA 2007 Service Repair Manual CONTROL LINKAGE
TM-675
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Disconnect connectors (A) and then remove bracket (1).
4. While pressing the lock of the select cable in t](/manual-img/5/57395/w960_57395-5620.png)
CONTROL LINKAGE
TM-675
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Disconnect connectors (A) and then remove bracket (1).
4. While pressing the lock of the select cable in the direction of the
arrow shown, remove the select cable from the selector lever.
5. While pressing the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the shifter lever.
6. While pulling the lock of the select cable in the direction of the
arrow shown, remove the select cable from the cable mounting
bracket.
7. While pulling the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the cable mounting
bracket.
8. Remove the control lever knob.
9. Remove console finisher assembly and the center console
assembly. Refer to IP-11, "
Removal and Installation".
10. Shift the control lever to the neutral position.
11. While pressing the lock of the select cable in the direction of the
arrow shown, remove the select cable from the control device
assembly.
12. While pressing the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the control device
assembly.
13. While pulling the lock of the select cable in the direction of the
arrow shown, remove the select cable from the control device
assembly.
14. While pulling the lock of the shift cable in the direction of the
arrow shown, remove the shift cable from the control device
assembly.
15. Remove the control device assembly.
16. Remove the heat plate.
17. Remove the bracket.
JPDIA0240ZZ
JPDIC0066ZZ
JPDIC0067ZZ
JPDIC0066ZZ
JPDIC0067ZZ
Page 5622 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-676
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
CONTROL LINKAGE
18. Remove the grommet and then remove the shift cable and select cable from the vehicle.
INSTALLATION
Installation is in the reverse order o NISSAN TIIDA 2007 Service Repair Manual TM-676
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
CONTROL LINKAGE
18. Remove the grommet and then remove the shift cable and select cable from the vehicle.
INSTALLATION
Installation is in the reverse order o](/manual-img/5/57395/w960_57395-5621.png)
TM-676
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
CONTROL LINKAGE
18. Remove the grommet and then remove the shift cable and select cable from the vehicle.
INSTALLATION
Installation is in the reverse order of removal.
Shift the control lever to the neutral position.
Securely assemble each cable and the selector lever and shifter lever.
Securely assemble each cable and the cable mounting bracket.
Securely assemble each cable and the control device assembly.
Make sure that the claws of grommet are in contact with the floor.
Be careful about the installation direction and push the control lever knob into the control lever.
CAUTION:
Never reuse control lever knob.
Tapping work for tapping bolt is not applied to new clutch housing. Do not perform tapping by other than
screwing tapping bolt because tapping is formed by screwing tapping bolt into clutch housing.
CAUTION:
Never reuse tapping bolt.
Install the select cable (the control device assembly side) with the following procedure.
1. While pulling the lock of the select cable in the direction of the
arrow shown, install the select cable to the control device
assembly.
2. Slide the lock (1) of the select cable in the direction of the arrow
as shown to pull up the stopper (2) of the select cable.
3. Install the end of the select cable to the pin of the control device
assembly.
4. Install the lever stopper pin (1) or a pin [3 mm (0.12 in) dia.] to
the control device assembly.
CAUTION:
Select cable cannot be adjusted accurately without a use of
a lever stopper pin or a pin [3 mm (0.12 in) dia.].
NOTE:
A lever stopper pin is not included in control device assembly.
Therefore, if the control device assembly is not replaced, pre-
pare a pin [3 mm (0.12 in) dia.].
5. Check that the control lever does not move in the direction of the
select. If it moves, repeat step 3.
6. Shift the control lever to 4th gear position.
JPDIC0067ZZ
JPDIC0064ZZ
JPDIC0069ZZ
Page 5623 of 5883
CONTROL LINKAGE
TM-677
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
7. With the stopper (1) of the select cable pressed into all the way,
slide lock (2) of the select cable all the way in the direction of the
arrow.
8. Remove the lever stopper pin or a pin [3 mm (0.12 in) dia.] from
the control device assembly.
9. Shift the control lever to each gear position to check that there is
no binding. If any, repeat step 3.
InspectionINFOID:0000000001381640
After installing, confirm the following items:
When the control lever is shifted to 1st-2nd side and 5th-6th side, confirm the control lever returns to neutral
position smoothly.
When the control lever is shifted to each position, make sure there is no binding or disconnection in each
boot.
JPDIC0065ZZ
Page 5624 of 5883
TM-678
< ON-VEHICLE REPAIR >[6MT: RS6F94R]
AIR BREATHER HOSE
AIR BREATHER HOSE
Exploded ViewINFOID:0000000001381641
MR18DE ENGINE MODELS
K9K ENGINE MODELS
Removal and InstallationINFOID:0000000001381642
REMOVAL
SCIA7629E
1. Air cleaner case 2. Air breather hose 3. Air duct
4. Clip 5. Transaxle assembly ⇐Two way connector
ALDIA0192ZZ
1. Air duct 2. Transaxle assembly 3. Air breather hose
