2007 NISSAN TIIDA Service Repair Manual

radiator cap winter tyres ad blue water pump fuse diagram oil filter

Load previous 8 pages

Page 1873 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-524
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P0605 ECM
P0605 ECM
DescriptionINFOID:0000000001693314
The ECM consists of a microcomputer and connectors for signal
input and output and for

Page 1874 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0605 ECM
EC-525
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Diagnosis ProcedureINFOID:0000000001693316
1.INSPECTION START
With CONSULT-III
1. Turn ignition swit

Page 1875 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-526
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1065 ECM
P1065 ECM
DescriptionINFOID:0000000001693317
ECM has the memory function of the DTC memory, the air-fuel ratio
feedback compensation

Page 1876 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1065 ECM
EC-527
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> INSPECTION END
2.REPLACE ECM
1. Replace ECM.
2. Go to EC-388, "
ADDITIONAL SERVICE WHEN REPLAC

Page 1877 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-528
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1111 IVT CONTROL SOLENOID VALVE
P1111 IVT CONTROL SOLENOID VALVE
DescriptionINFOID:0000000001693320
Intake valve timing control solenoid valv

EC-528
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1111 IVT CONTROL SOLENOID VALVE
P1111 IVT CONTROL SOLENOID VALVE
DescriptionINFOID:0000000001693320
Intake valve timing control solenoid valve is activated by ON/OFF
pulse duty (ratio) signals from the ECM.
The intake valve timing control solenoid valve changes the oil
amount and direction of flow through intake valve timing control unit
or stops oil flow.
The longer pulse width advances valve angle.
The shorter pulse width retards valve angle.
When ON and OFF pulse widths become equal, the solenoid valve
stops oil pressure flow to fix the intake valve angle at the control
position.
DTC LogicINFOID:0000000001693321
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 5 seconds.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Go to EC-528, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001693322
1.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect intake valve timing control solenoid valve harness connector.
3. Turn ignition switch ON.
4. Check the voltage between intake valve timing control solenoid valve harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTION PART
PBIB1842E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P 1111Intake valve timing control
solenoid valve circuitAn improper voltage is sent to the ECM
through intake valve timing control solenoid
valve. Harness or connectors
(Intake valve timing control solenoid valve
circuit is open or shorted.)
Intake valve timing control solenoid valve
IVT control solenoid valve
Ground Voltage
Connector Terminal
F23 1 Ground Battery voltage

Page 1878 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1111 IVT CONTROL SOLENOID VALVE
EC-529
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Check the following.
Harness connectors E8, F8
Harness for open or short

Page 1879 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-530
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
P1111 IVT CONTROL SOLENOID VALVE
2. Provide 12V DC between intake valve timing control solenoid
valve terminals 1 and 2, and then interrupt it

Page 1880 of 5883

NISSAN TIIDA 2007 Service Repair Manual P1121 ELECTRIC THROTTLE CONTROL ACTUATOR
EC-531
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1121 ELECTRIC THROTTLE CONTROL ACTUATOR
DescriptionINFOID:0000000001

P1121 ELECTRIC THROTTLE CONTROL ACTUATOR
EC-531
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P1121 ELECTRIC THROTTLE CONTROL ACTUATOR
DescriptionINFOID:0000000001693324
Electric throttle control actuator consists of throttle control motor, throttle position sensor, etc.
The throttle control motor is operated by the ECM and it opens and closes the throttle valve.
The throttle position sensor detects the throttle valve position, and the opening and closing speed of the throt-
tle valve and feeds the voltage signals to the ECM. The ECM judges the current opening angle of the throttle
valve from these signals and the ECM controls the throttle control motor to make the throttle valve opening
angle properly in response to driving condition.
DTC LogicINFOID:0000000001693325
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION A AND B
1. Turn ignition switch ON and wait at least 1 second.
2. Set shift lever to D (A/T), 1st (M/T) position and wait at least 3 seconds.
3. Set shift lever to P or N (A/T), Neutral (M/T) position.
4. Turn ignition switch OFF and wait at least 10 seconds.
5. Turn ignition switch ON and wait at least 1 second.
6. Set shift lever to D (A/T), 1st (M/T) position and wait at least 3 seconds.
7. Set shift lever to P or N (A/T), Neutral (M/T) position.
8. Turn ignition switch OFF, wait at least 10 seconds, and then turn ON.
9. Check DTC.
Is DTC detected?
YES >> Go to EC-531, "Diagnosis Procedure".
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE FOR MALFUNCTION C
1. Turn ignition switch ON and wait at least 1 second.
2. Set shift lever to D (A/T), 1st (M/T) position and wait at least 3 seconds.
3. Set shift lever to P or N (A/T), Neutral (M/T) position.
4. Start engine and let it idle for 3 seconds.
5. Check DTC.
Is DTC detected?
YES >> Go to EC-531, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001693326
1.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR VISUALLY
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1121Electric throttle control
actuatorA)Electric throttle control actuator does not func-
tion properly due to the return spring malfunc-
tion.
Electric throttle control actuator
B)Throttle valve opening angle in fail-safe mode is
not in specified range.
C) ECM detect the throttle valve is stuck open.

Load next 8 pages
