NISSAN TIIDA 2007 Service Repair Manual SEC-112
< ECU DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
REAR WIPER CONTROL
BCM detects a rear wiper stopping position according to a rear wiper auto stop signal.
When a rea

SEC-112
< ECU DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
BCM (BODY CONTROL MODULE)
REAR WIPER CONTROL
BCM detects a rear wiper stopping position according to a rear wiper auto stop signal.
When a rear wiper auto stop signal is in the condition listed below, BCM stops power supply to rear wiper after
rear wiper is activated for five seconds.
NOTE:
The above operation is repeated when operating the rear wiper switch one minute after the stop of the rear
wiper caused by Fail-safe.
TURN SIGNAL LAMP CONTROL
BCM detects the turn signal lamp circuit status from the terminal voltage.
BCM increases the turn signal lamp blinking speed if the bulb or harness open is detected with the turn signal
lamp operating.
NOTE:
The blinking speed is normal while activating the hazard warning lamp.
LIGHT & RAIN SENSOR MALFUNCTION DETECTION FUNCTION
BCM controls the following items when LIGHT & RAIN sensor has a malfunction.
Auto Light Control
Headlamp is turned ON.
Front Wiper Control
The condition just before the activation of Fail-safe is maintained until the front wiper switch is turned OFF.
Display contents of CONSULT Fail-safe Cancellation
B2190: NATS ANTENNA AMP Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
B2191: DIFFERENCE OF KEY Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
B2192: ID DISCORD BCM-ECM Fuel cut (ECM) Erase DTC
B2193: CHAIN OF BCM-ECM Fuel cut (ECM) Erase DTC
B2194: DISCORD BCM-I-KEY Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
B2195: ANTI SCANNING Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
B2196: DONGLE NG Inhibits engine cranking
Inhibits steering lock unlocking (Intelligent Key unit)
Fuel cut (ECM)Erase DTC
Ignition switch Rear wiper switch Auto stop signal
ONOFFRear wiper stop position signal cannot be
input 5 seconds.
ON The signal does not change for 5 seconds.

Page 4738 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCM (BODY CONTROL MODULE)
SEC-113
< ECU DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
DTC Inspection Priority ChartINFOID:0000000001404224
DTC IndexINFOID:00000000014042

Page 4739 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-114
< ECU DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)
Reference ValueINFOI

SEC-114
< ECU DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)
Reference ValueINFOID:0000000001404226
Refer to IPDM E/R.
Fail SafeINFOID:0000000001404229
CAN communication control
When CAN communication with ECM and BCM is impossible, IPDM E/R performs fail-safe control. After CAN
communication recovers normally, it also returns to normal control.
If no CAN communication is available with ECM
*1: HR engine models
*2: MR engine and K9K engine models
If no CAN communication is available with BCM
Ignition relay malfunction detection function
IPDM E/R monitors the voltage at the contact circuit and excitation coil circuit of the ignition relay inside it.
IPDM E/R judges the ignition relay error if the voltage differs between the contact circuit and the excitation
coil circuit.
If the ignition relay cannot turn OFF due to contact seizure, it activates the tail lamp relay for 10 minutes to
alert the user to the ignition relay malfunction when the ignition switch is turned OFF.
Control part Fail-safe in operation
Cooling fan The cooling fan relay-2*
1 or the cooling fan relay-3*2 turns ON when the ignition switch
is turned ON
Turns off the fan motor low relay when the ignition switch is turned OFF
A/C compressor A/C relay OFF
Control part Fail-safe in operation
Headlamp The headlamp low relay turns ON when the ignition switch is turned ON
The headlamp low relay turns OFF when the ignition switch is turned OFF
Headlamp high relay OFF
Parking lamps
License plate lamps
Tail lamps
Illuminations The tail lamp relay turns ON when the ignition switch is turned ON
The tail lamp relay turns OFF when the ignition switch is turned OFF
Front wiper The status just before activation of fail-safe control is maintained until the ignition
switch is turned OFF while the front wiper is operating at LO or HI speed.
The front wiper is operated at LO speed until the ignition switch is turned OFF if the
fail-safe control is activated while the front wiper is set in the INT mode and the front
wiper motor is operating.
Front fog lamps Front fog lamp relay OFF
Starter motor Inhibit relay OFF
Rear window defogger Rear window defogger relay OFF
Headlamp washer Headlamp washer relay OFF
PTC heater PTC heater relay OFF
DTC Ignition switch Ignition relay Tail lamp relay
—ONON—
—OFFOFF—
B2098: IGN RLY ON OFFONON (10 minutes)
B2099: IGN RLY OFF ON OFF —

Page 4740 of 5883

NISSAN TIIDA 2007 Service Repair Manual IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
SEC-115
< ECU DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
NOTE:
The tail lamp relay is turned OFF when the

Page 4741 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-116
< SYMPTOM DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY SYSTEM SYMPTOMS
SYMPTOM DIAGNOSIS
VEHICLE SECURITY SYSTEM SYMPTOMS
Symptom TableINFOID:0000000001404231
*: Check the syst

Page 4742 of 5883

NISSAN TIIDA 2007 Service Repair Manual NATS (NISSAN ANTI-THEFT SYSTEM) SYMPTOMS
SEC-117
< SYMPTOM DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
NATS (NISSAN ANTI-THEFT SYSTEM) SYMPTOMS
Symptom TableINFOID:000

Page 4743 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-118
< ON-VEHICLE MAINTENANCE >[WITHOUT INTELLIGENT KEY SYSTEM]
PRE-INSPECTION FOR DIAGNOSTIC
ON-VEHICLE MAINTENANCE
PRE-INSPECTION FOR DIAGNOSTIC
Basic InspectionINFOID:0000000001404233
1.INSPECTI

Page 4744 of 5883

NISSAN TIIDA 2007 Service Repair Manual SR-1
RESTRAINTS
C
D
E
F
G
I
J
K
L
M
SECTION SR
A
B
SR
N
O
P
CONTENTS
SRS AIRBAG
PRECAUTION ...............................................2
PRECAUTIONS ................................................

SR-1
RESTRAINTS
C
D
E
F
G
I
J
K
L
M
SECTION SR
A
B
SR
N
O
P
CONTENTS
SRS AIRBAG
PRECAUTION ...............................................2
PRECAUTIONS ...................................................2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
2
Precaution for SRS "AIR BAG" and "SEAT BELT
PRE-TENSIONER" Service ......................................
2
PREPARATION ............................................3
PREPARATION ...................................................3
Special Service Tool .................................................3
ON-VEHICLE REPAIR ..................................4
DRIVER AIR BAG MODULE ...............................4
Removal and Installation ...........................................4
SPIRAL CABLE ..................................................7
Removal and Installation ...........................................7
FRONT PASSENGER AIR BAG MODULE ........9
Removal and Installation ...........................................9
SIDE CURTAIN AIR BAG MODULE ................10
Component ..............................................................10
Removal and Installation .........................................10
SIDE AIR BAG (SATELLITE) SENSOR ...........12
Removal and Installation .........................................12
PASSENGER AIR BAG DEACTIVATION
SWITCH .............................................................
13
Passenger Air Bag Deactivation Switch ..................13
FRONT SEAT BELT PRE-TENSIONER ...........14
Removal and Installation .........................................14
DIAGNOSIS SENSOR UNIT .............................15
Removal and Installation .........................................15
DISPOSAL OF AIR BAG MODULE AND
SEAT BELT PRE-TENSIONER ........................
16
Caution for Air Bag Module and Seat Belt Pre-ten-
sioner .......................................................................
16
COLLISION DIAGNOSIS ..................................23
For Frontal Collision ................................................23
For Side and Rollover Collision ...............................24
