NISSAN TIIDA 2007 Service Repair Manual FRONT DRIVE SHAFT
FAX-11
< REMOVAL AND INSTALLATION >
C
E
F
G
H
I
J
K
L
MA
B
FA X
N
O
P
Check boot for cracks or other damage, and for grease leakage.
If damaged, disassemble drive shaft to verify

Page 3146 of 5883

NISSAN TIIDA 2007 Service Repair Manual FAX-12
< REMOVAL AND INSTALLATION >
FRONT DRIVE SHAFT
Do not pull on wheel sensor harness.
3. Remove transverse link ball joint nut and bolt. Then, remove transverse link from steering knuckle.
4. Rem

FAX-12
< REMOVAL AND INSTALLATION >
FRONT DRIVE SHAFT
Do not pull on wheel sensor harness.
3. Remove transverse link ball joint nut and bolt. Then, remove transverse link from steering knuckle.
4. Remove cotter pin, then loosen hub lock nut using power tool.
CAUTION:
Temporarily leave the hub lock nut installed to prevent damage to threads.
5. Separate the drive shaft from the wheel hub and bearing assem-
bly by lightly tapping the end of the drive shaft using a hammer
or suitable tool and wood block, and then remove hub lock nut.
NOTE:
Use a suitable puller if wheel hub and bearing assembly and
drive shaft cannot be separated after performing the above pro-
cedure.
6. Remove the drive shaft from the wheel hub and bearing assem-
bly.
CAUTION:
Do not apply an excessive angle to drive shaft joint when
removing from the wheel hub and bearing assembly,
Do not excessively extend slide joint.
Do not allow drive shaft to hang down. Support the entire drive shaft.
7. Remove the plate bolts and plate.
8. Remove the drive shaft from the transaxle assembly.
CAUTION:
Do not apply an excessive angle to drive shaft joint when removing from the transaxle.
Do not excessively extend slide joint.
Do not allow drive shaft to hang down. Support the entire drive shaft.
9. If necessary, remove the support bearing bracket bolts and the support bearing bracket.
INSPECTION AFTER REMOVAL
Move joint up/down, left/right, and in axial direction. Check for any rough movement or significant looseness.
Check boot for cracks or other damage, and for grease leakage.
If damaged, disassemble drive shaft to verify damage, and repair
or replace as necessary.
Check for cracks or other damage to the support bearing bracket,
replace as necessary.
INSTALLATION
Installation is in the reverse order of removal. Note the following:
Refer to "COMPONENTS" for tightening torque.
CAUTION:
Do not reuse non-reusable parts.
In order to prevent damage to differential side oil seal, place Tool
onto oil seal before inserting drive shaft as shown. Slide drive shaft
into slide joint and tap with a hammer to install securely.
SDIA1821E
SDIA1190J
Tool number : KV38106700 (J-34296)
SDIA0593E

Page 3147 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT DRIVE SHAFT
FAX-13
< REMOVAL AND INSTALLATION >
C
E
F
G
H
I
J
K
L
MA
B
FA X
N
O
P
When installing the support bearing bracket (1), note the following:
a. Tighten the support bearing bracket bo

Page 3148 of 5883

NISSAN TIIDA 2007 Service Repair Manual FAX-14
< DISASSEMBLY AND ASSEMBLY >
FRONT DRIVE SHAFT
DISASSEMBLY AND ASSEMBLY
FRONT DRIVE SHAFT
Disassembly and Assembly (Left Side)INFOID:0000000001716803
DISASSEMBLY
Transaxle Side
1. Mount drive s

Page 3149 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT DRIVE SHAFT
FAX-15
< DISASSEMBLY AND ASSEMBLY >
C
E
F
G
H
I
J
K
L
MA
B
FA X
N
O
P
6. Remove snap ring using a suitable tool, then remove spider
assembly from shaft.
7. Remove boot from shaft.
8.

Page 3150 of 5883

NISSAN TIIDA 2007 Service Repair Manual FAX-16
< DISASSEMBLY AND ASSEMBLY >
FRONT DRIVE SHAFT
1. Install new boot and new small boot band on shaft.
CAUTION:
Do not reuse boot or boot band.
Cover drive shaft serration with tape to preven

Page 3151 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT DRIVE SHAFT
FAX-17
< DISASSEMBLY AND ASSEMBLY >
C
E
F
G
H
I
J
K
L
MA
B
FA X
N
O
P
2. Pull and tighten the boot band using suitable tool until both
pawls of boot band are secured in the boot band

Page 3152 of 5883

NISSAN TIIDA 2007 Service Repair Manual FAX-18
< DISASSEMBLY AND ASSEMBLY >
FRONT DRIVE SHAFT
4. Attach new circlip to shaft. Thread nut onto end of joint sub-
assembly and press fit using suitable tool.
CAUTION:
Do not reuse circlip.
C
