Page 4369 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-62 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 9 (P)GroundCombination switch INPUT 1InputCombination switch (Wiper intermit- tent dial 4)All switch OFF 1.4V Turn signal switch LH 1.3V Turn signa

Page 4370 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-63 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 13 (V)GroundCombination switch OUTPUT 1OutputCombination switchAll switch OFF (Wiper intermittent dial 4)0V Front

Page 4371 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-64 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 24 (O)GroundIgnition power sup- plyInputIgnition switch OFF or ACC 0V Ignition switch ON or START Battery voltage 25 (L)GroundDoor lock/unlock switc

Page 4372 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-65 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 27 (Y)GroundCombination switch INPUT 4InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4V Light

Page 4373 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-66 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 28 (R)GroundCombination switch INPUT 2InputCombination switch (Wiper intermit- tent dial 4)All switch OFF 1.4V Lighting switch PASS 1.3V Lighting s

Page 4374 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-67 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 324 (LG)GroundDoor lock status indi- catorOutputDoor lock status indicatorON Battery voltage OFF 0V 33 (G)GroundCom

Page 4375 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-68 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 527 (GR)Ground PTC relay 2 control Output Ignition ONPTC heater 2 ON 0V PTC heater 2 OFF Battery voltage 58 (Y)Ground Door unlock sensor Input Driver

Page 4376 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-69 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 1: Hatchback 2: Sedan 3: Manual A/C 4: Superlock 5: Remote keyless entry 6: Intelligent Key 7: LHD diesel69 (G)Grou
