3. Remove the check link bolt.
4. Remove the hinge nuts and the door assembly.
Installation
Installation is in the reverse order of removal.
BACK DOOR
Removal
1. Remove the back door glass. Refer to GW-18, "Removal and Installation".
2. Remove the back door lock assembly. Refer to DLK-757, "
Removal and Installation".
3. Remove the back door wire harness.
4. Remove the rear washer nozzle and hose from the back door. Refer to WW-80, "
Removal and Installa-
tion".
5. Support the back door.
CAUTION:
Two technicians should be used to avoid damaging the back door during removal.
6. Remove the back door stays.
7. Remove the door side nuts and the back door assembly.
Installation
Installation is in the reverse order of removal.
Align the back door. Refer to DLK-743, "
Fitting Adjustment". 14.7 N·m (1.5 kg-m, 11 ft-lb)
PIIB6543E
24.5 N·m (2.5 kg-m, 18 ft-lb)
PIIB6522E
LIIA2639E
Page 1338 of 5883
FUEL FILLER LID OPENER
DLK-749
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
FUEL FILLER LID OPENER
Removal and Installation of Fuel Filler Lid OpenerINFOID:0000000001732061
REMOVAL
1. Remove trunk side finisher (RH). Refer to XX-XX, "*****".
2. Remove fuel filler lid opener cable lock ring.
3. Remove front and rear kicking plates. Refer to XX-XX, "*****"
.
4. Remove rear cushion assembly. Refer to XX-XX, "*****"
.
5. Remove the bolts and the fuel filler lid opener handle.
6. Remove fuel filler lid opener cable clips from the vehicle.
7. Remove the fuel filler lid opener cable (LH drive).
8. Remove the fuel filler lid opener cable (RH drive).
PIIB3831J
LIIA2670E
LIIA2629E
ALKIA0651GB
Page 1339 of 5883
DLK-750
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
FUEL FILLER LID OPENER
INSTALLATION
Installation is in the reverse order of removal.
Page 1340 of 5883
![NISSAN TIIDA 2007 Service Repair Manual FRONT DOOR LOCK
DLK-751
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
FRONT DOOR LOCK
Component Parts LocationINFOID:0000000001732062
Removal and Instal NISSAN TIIDA 2007 Service Repair Manual FRONT DOOR LOCK
DLK-751
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
FRONT DOOR LOCK
Component Parts LocationINFOID:0000000001732062
Removal and Instal](/manual-img/5/57395/w960_57395-1339.png)
FRONT DOOR LOCK
DLK-751
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
FRONT DOOR LOCK
Component Parts LocationINFOID:0000000001732062
Removal and InstallationINFOID:0000000001732063
REMOVAL
1. Remove front door finisher. Refer to XX-XX, "*****" .
2. Fully close front door window.
3. Remove the front door sealing screen.
NOTE:
If sealing screen is reused, cut butyl tape in a way that leaves it on the sealing screen.
4. Remove front door rear glass run channel. Refer to XX-XX, "*****"
.
5. Remove the cables from the holder.
6. Remove inside handle bolt, and slide the handle toward the rear
of the vehicle. disengage the handle from the door panel, and
remove the inside handle.
7. Disengage the handle from the door panel, and remove the inside handle.
1. Front door 2. Inside handle 3. Inside handle cable
4. Door lock assembly 5. Outside handle cable 6. TORX bolt (T30)
7. Key cylinder connecting rod 8. Grommet 9. TORX bolt (T30)
10. Rear gasket 11. Door key cylinder assembly
(Driver's side)
Outside handle escutcheon
(passenger's side)12. Outside handle
13. Front gasket 14. Lock knob cable 15. Holder
16. Outside handle bracket
PIIB6523E
PIIB6524E
Page 1341 of 5883
DLK-752
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
FRONT DOOR LOCK
8. Disconnect the inside handle cable and lock knob cable from the
inside handle.
CAUTION:
During removal and installation, work so as not to bend the
ends of the lock knob cable and inside handle cable.
9. Remove the door side grommet, and the door key cylinder
assembly (escutcheon) bolt.
10. Remove the key cylinder connecting rod (key cylinder side).
11. If equipped, disconnect the door antenna, the door request
switch connector and remove the harness clamp. (Vehicle with
intelligent key systems only).
12. Remove the door cylinder assembly while pulling the outside
handle forward.
13. Pull the outside door handle forward and then slide it toward the
rear of the vehicle to remove.
14. Remove the front and rear gaskets.
PIIB6525E
PIIB5808E
PIIB5809E
PIIB5810E
PIIB6526E
Page 1342 of 5883
FRONT DOOR LOCK
DLK-753
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
15. Remove the door lock assembly bolts.
16. Slide the outside handle bracket toward the rear of the vehicle,
and remove the assembly.
17. If equipped, disconnect the door lock assembly electrical connector.
18. Separate the outside handle cable from the outside handle
bracket.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
To install each rod, be sure to rotate the rod holder until a click is felt.
When installing door lock assembly, be careful when rotating the outside handle cable as shown in
the figure.
- Place the outside handle bracket cable on the inside of door
lock assembly before installing. 5.8 N·m (0.6 kg-m, 51.4 in-lb)
PIIB6527E
PIIB6528E
PIIB5815E
PIIB6529E
Page 1343 of 5883
DLK-754
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
REAR DOOR LOCK
REAR DOOR LOCK
Component Parts LocationINFOID:0000000001732064
Removal and InstallationINFOID:0000000001732065
REMOVAL
1. Remove the partition glass. Refer to XX-XX, "*****".
2. Support door glass while lifting it up to the door window completely closed position.
3. Remove inside handle bolt, slide handle toward rear of vehicle,
disconnect it from the door panel, and remove the inside handle.
4. Disconnect the inside handle and lock knob cables from the
inside handle.
CAUTION:
During removal and installation, do not to bend the ends of
the lock knob cable and inside handle cable.
1. Rear door 2. Inside handle 3. Inside handle cable
4. Door lock assembly 5. TORX bolt (T30) 6. Outside handle cable
7. Grommet 8. TORX bolt (T30) 9. Rear gasket
10. Outside handle escutcheon 11. Outside handle 12. Front gasket
13. Lock knob cable 14. Outside handle bracket
PIIB6530E
PIIB6524E
PIIB6525E
Page 1344 of 5883
REAR DOOR LOCK
DLK-755
< REMOVAL AND INSTALLATION >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
5. Remove the door side grommet, and the outside handle
