Page 17 of 5883
AV-12
< COMPONENT DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
STEERING SWITCH
1. Disconnect spiral cable connector M102.
2. Check continuity between spiral cable harness connector M30
(A) and M102 (B).
Does the spiral cable check OK?
YES >> Inspection End.
NO >> Replace spiral cable. Refer to XX-XX, "*****"
.
Spiral cable
Continuity
Connector Terminal Connector Terminal
M3024
M10220
Ye s 31 17
32 16
ALNIA0333GB
Page 18 of 5883
![NISSAN TIIDA 2007 Service Repair Manual AV
MICROPHONE SIGNAL CIRCUIT
AV-13
< COMPONENT DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
MICROPHONE SIGNAL CIRCUIT
DescriptionINFOID:0000000001728771
Voice signals are transmi NISSAN TIIDA 2007 Service Repair Manual AV
MICROPHONE SIGNAL CIRCUIT
AV-13
< COMPONENT DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
MICROPHONE SIGNAL CIRCUIT
DescriptionINFOID:0000000001728771
Voice signals are transmi](/manual-img/5/57395/w960_57395-17.png)
AV
MICROPHONE SIGNAL CIRCUIT
AV-13
< COMPONENT DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
MICROPHONE SIGNAL CIRCUIT
DescriptionINFOID:0000000001728771
Voice signals are transmitted from the microphone to the AV control unit using the microphone signal circuits.
Diagnosis ProcedureINFOID:0000000001728772
1.CHECK HARNESS BETWEEN AV CONTROL UNIT AND MICROPHONE
1. Turn ignition switch OFF.
2. Disconnect AV control unit connector and microphone connector.
3. Check continuity between AV control unit harness connector M44 and microphone harness connector
R15.
4. Check continuity between AV control unit harness connector M44 and ground.
Are the continuity test results as specified?
YES >> GO TO 2
NO >> Repair harness or connector.
2.CHECK MICROPHONE POWER SUPPLY
1. Connect AV control unit connector and microphone connector.
2. Turn ignition switch ON.
3. Check voltage between microphone harness connector R15 ter-
minal 4 and ground.
Is voltage reading approx. 5 volts?
YES >> GO TO 3
NO >> Replace AV control unit. Refer to XX-XX, "*****"
.
3.CHECK MICROPHONE SIGNAL
Check signal between AV control unit harness connector M44 terminals 27 and 28 with CONSULT-III or and
oscilliscope.
Te r m i n a l Te r m i n a l
Continuity
Connector Terminal Connector Terminal
M4427
R151
Ye s 28 2
29 4
Te r m i n a l
— Continuity
Connector Terminal
M447
Ground No 8
29
4 - Ground : Approx. 5V
WKIA5796E
Page 19 of 5883
AV-14
< COMPONENT DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
MICROPHONE SIGNAL CIRCUIT
Are voltage readings as specified?
YES >> Replace AV control unit. Refer to XX-XX, "*****".
NO >> Replace microphone. Refer to XX-XX, "*****"
.
Connector(+) (-)
Reference signal
Terminal Terminal
M44 27 28While speaking into MIC
PKIB5037J
Page 20 of 5883
AV
AV CONTROL UNIT
AV-15
< ECU DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
ECU DIAGNOSIS
AV CONTROL UNIT
Reference ValueINFOID:0000000001728621
TERMINAL LAYOUT
PHYSICAL VALUES
JPNIA0230ZZ
Te r m i n a l
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
2
(L)3
(G)Sound signal front LH OutputIgnition
switch
ONVoice output
4
(LG)5
(Y)Sound signal rear LH OutputIgnition
switch
ONVoice output
6
(R)15
(B)Steering switch signal A InputIgnition
switch
ONKeep pressing SOURCE
switch. 0 V
Keep pressing SEEK UP
switch.1.7 V
Keep pressing VOL UP
switch.3.3 V
Except for above. 5 V
7
(R)Ground ACC power supply InputIgnition
switch
ACC−Battery voltage
11
(BR)12
(P)Sound signal front RH OutputIgnition
switch
ONVoice output
SKIB3609E
SKIB3609E
SKIB3609E
Page 21 of 5883
AV-16
< ECU DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
AV CONTROL UNIT
13
(O)14
(V)Sound signal rear RH OutputIgnition
switch
ONVoice output
15
(B)Ground Steering switch signal GND —Ignition
switch
ON—0 V
16
(Y)15
(B)Steering switch signal B InputIgnition
switch
ONKeep pressing switch.0 V
Keep pressing SEEK
DOWN switch.1.7 V
Keep pressing VOL DOWN
switch.3.3 V
Except for above. 5 V
17
(SB)— Immobilizer — — — —
18
(Y)GroundVehicle speed signal (8-
pulse) InputIgnition
switch
ONWhen vehicle speed is ap-
prox. 40 km/h (25MPH)
19
(LG)Ground Battery power supply InputIgnition
switch
OFF— Battery voltage
31
(B)Ground GND —Ignition
switch
ON—0 V
35
(B/W)36 Microphone signal InputIgnition
switch
ONSounds
36 Ground Microphone GND —Ignition
switch
ON—0 V
37
(L)36 Microphone VCC OutputIgnition
switch
ON—5 V
42 — Antenna signal Input — — —Terminal
(Wire color)Description
ConditionReference value
(Approx.)
+ – Signal nameInput/
Output
SKIB3609E
SKIA6649J
PKIB5037J
Page 22 of 5883
AV
AV CONTROL UNIT
AV-17
< ECU DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Wiring DiagramINFOID:0000000001728622
ALNWA0138GB
Page 23 of 5883
AV-18
< ECU DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
AV CONTROL UNIT
ALNWA0139GB
Page 24 of 5883
![NISSAN TIIDA 2007 Service Repair Manual AV
MULTI AV SYSTEM SYMPTOMS
AV-19
< SYMPTOM DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
SYMPTOM DIAGNOSIS
MULTI AV SYSTEM SYMPTOMS
Symptom TableINFOID:0000000001728624
RELATED T NISSAN TIIDA 2007 Service Repair Manual AV
MULTI AV SYSTEM SYMPTOMS
AV-19
< SYMPTOM DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
SYMPTOM DIAGNOSIS
MULTI AV SYSTEM SYMPTOMS
Symptom TableINFOID:0000000001728624
RELATED T](/manual-img/5/57395/w960_57395-23.png)
AV
MULTI AV SYSTEM SYMPTOMS
AV-19
< SYMPTOM DIAGNOSIS >[AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
SYMPTOM DIAGNOSIS
MULTI AV SYSTEM SYMPTOMS
Symptom TableINFOID:0000000001728624
RELATED TO AUDIO
RELATED TO HANDS FREE PHONE
Check that the cellular phone is corresponding type (Bluetooth® enabled) when the hands free related mal-
function vehicle is in service before performing a diagnosis.
There is a case that malfunction occurs due to the version change of the phone type, etc. even though it is a
corresponding type. Therefore, confirm it by changing the cellular phone to another corresponding type
phone, and check that it operates normally. It is necessary to distinguish whether the cause is the vehicle or
cellular phone. Check to ensure the customers phone is supported by checking the phone compatibility for
the hands free system.
Trouble diagnosis chart by symptom
RELATED TO STEERING SWITCH
Symptom Check items Possible malfunction location / Action to take
Audio sound is not heard.No sound from all speakers Audio unit (XX-XX, "*****"
)
Sound is not heard only from the specif-
ic places (Front RH, rear RH, front LH
and rear LH).Sound signal circuit of suspect system
Symptoms Check items Possible malfunction location / Action to take
Does not recognize cellular
phone connection. Repeat the registration of cellular phone. Audio unit (XX-XX, "*****"
)
Hands free phone cannot be
established. Hands free phone operation can be
made, but the communication cannot
be established.
Hands free phone operation can be
performed, however, voice between
each other cannot be heard during the
conversation.Audio unit (XX-XX, "*****"
)
The other party's voice cannot
be heard by hands free phone.No sound from all speakers Audio unit (XX-XX, "*****"
)
Sound is not heard only from the specific
places (Front RH or front LH).Sound signal circuit (TEL voice)
Originating sound is not heard
by the other party with hands
free phone communication.Sound operation function is normal. Audio unit (XX-XX, "*****"
)
Sound operation function does not work. Microphone signal circuit (XX-XX, "*****"
)
Symptoms Possible malfunction location / Action to take
All steering switches are not operated. Steering switch signal ground circuit (XX-XX, "*****"
)
Only specified switch cannot be operated. Steering switch (XX-XX, "*****"
)
“MENU UP”, “VOL UP” and “SOURCE” switches are not op-
erated.Steering switch signal A circuit (XX-XX, "*****"
)
“ ”, “MENU DOWN” and “VOL DOWN” switches are not
operated.Steering switch signal B circuit (XX-XX, "*****"
)
