Commercial Service ToolINFOID:0000000001696276
Tool nameDescription
(J-41810-NI)
Refrigerant identifier equipment (R-
134a)For checking refrigerant purity and
system contamination
Power toolLoosening bolts and nuts
RJIA0197E
PBIC0190E
Page 5666 of 5883
AIR CONDITIONER FILTER
VTL-5
< FUNCTION DIAGNOSIS >[AUTOMATIC AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
FUNCTION DIAGNOSIS
AIR CONDITIONER FILTER
DescriptionINFOID:0000000001696277
FUNCTION
The fresh air (A) and the recirculated air (B) drawn inside the pas-
senger compartment by the front blower motor (1) is kept clean (C)
on either mode by the air conditioner filter (2), located before the
evaporator (3), in the A/C unit assembly.
WJIA2253E
Page 5667 of 5883
![NISSAN TIIDA 2007 Service Repair Manual VTL-6
< ON-VEHICLE MAINTENANCE >[AUTOMATIC AIR CONDITIONER]
AIR CONDITIONER FILTER
ON-VEHICLE MAINTENANCE
AIR CONDITIONER FILTER
Removal and InstallationINFOID:0000000001696278
REPLACEMENT TIMING
Repl NISSAN TIIDA 2007 Service Repair Manual VTL-6
< ON-VEHICLE MAINTENANCE >[AUTOMATIC AIR CONDITIONER]
AIR CONDITIONER FILTER
ON-VEHICLE MAINTENANCE
AIR CONDITIONER FILTER
Removal and InstallationINFOID:0000000001696278
REPLACEMENT TIMING
Repl](/manual-img/5/57395/w960_57395-5666.png)
VTL-6
< ON-VEHICLE MAINTENANCE >[AUTOMATIC AIR CONDITIONER]
AIR CONDITIONER FILTER
ON-VEHICLE MAINTENANCE
AIR CONDITIONER FILTER
Removal and InstallationINFOID:0000000001696278
REPLACEMENT TIMING
Replace the air conditioner filter according to the maintenance schedules. Refer to MA-7, "Periodic Mainte-
nance".
NOTE:
The air conditioner filter caution label is located inside the glove box door.
REPLACEMENT PROCEDURES
1. Remove the instrument lower finisher and instrument lower cover (LH) for LHD only. Refer to IP-11,
"Removal and Installation".
2. Remove the glove box assembly and instrument lower cover (RH) for RHD only. Refer to IP-11, "
Removal
and Installation".
3. Compress the air conditioner filter (1) downward while sliding it
to the RH side of the vehicle to release the upper pawl.
4. Move the bottom of air conditioner filter (1) upward as shown to
release the bottom tab, then remove it.
5. Replace the air conditioner filter with new one and install the new filter in the A/C unit assembly.
CAUTION:
Make sure that the air conditioner filter lower tab is fully seated, and that the air conditioner upper
pawl is locked into place securing the new filter into the A/C unit assembly.
6. Install the glove box assembly and instrument lower cover (RH) for RHD only. Refer to IP-11, "
Removal
and Installation".
7. Install the instrument lower finisher and instrument lower cover (LH) for LHD only. Refer to IP-11,
"Removal and Installation".
SJIA0652E
Page 5668 of 5883
CONTROLLER
VTL-7
< ON-VEHICLE REPAIR >[AUTOMATIC AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
ON-VEHICLE REPAIR
CONTROLLER
Removal and InstallationINFOID:0000000001696279
REMOVAL
1. Remove cluster lid C and instrument finisher D. Refer to IP-11, "Removal and Installation".
2. Remove the front air control screws and release the front air
control clips, and then remove the front air control.
INSTALLATION
Installation is in the reverse order of removal.
Disassembly and AssemblyINFOID:0000000001696280
DISASSEMBLY
SJIA0687E
1. Front air control 2. FRE button 3. MODE ring
4. TEMP ring 5. A/C finisher 6. A/C button
7. TEMP button 8. REC button 9. LCD ring
10. Rear DEF button 11. AUTO button 12. FAN button
13. MODE button
ZJIA0641J
Page 5669 of 5883
VTL-8
< ON-VEHICLE REPAIR >[AUTOMATIC AIR CONDITIONER]
CONTROLLER
1. Remove rear DEF button (1) using a suitable tool (A) as shown.
2. Remove A/C button (1) using a suitable tool (A) as shown.
3. Remove FRE button (1) and REC button (2) using a suitable tool
as shown.
ASSEMBLY
Assembly is in the reverse order of disassembly.
ZJIA0792J
ZJIA0793J
ZJIA0794J
Page 5670 of 5883
IN-VEHICLE SENSOR
VTL-9
< ON-VEHICLE REPAIR >[AUTOMATIC AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
IN-VEHICLE SENSOR
Removal and InstallationINFOID:0000000001696282
REMOVAL
1. Remove instrument lower finisher. Refer to IP-11, "Removal and Installation".
2. Remove in-vehicle sensor screw (A), and then remove in-vehi-
cle sensor (1) from instrument lower finisher (2).
INSTALLATION
Installation is in the reverse order of removal.
SJIA0688E
Page 5671 of 5883
VTL-10
< ON-VEHICLE REPAIR >[AUTOMATIC AIR CONDITIONER]
SUNLOAD SENSOR
SUNLOAD SENSOR
Removal and InstallationINFOID:0000000001696283
REMOVAL
1. Remove instrument upper mask using a suitable tool as shown.
2. Disconnect sunload sensor connector, and then remove sunload
sensor (1).
INSTALLATION
Installation is in the reverse order of removal.
SJIA0689E
Page 5672 of 5883
INTAKE SENSOR
VTL-11
< ON-VEHICLE REPAIR >[AUTOMATIC AIR CONDITIONER]
C
D
E
F
G
H
J
K
L
MA
B
VTL
N
O
P
INTAKE SENSOR
Removal and InstallationINFOID:0000000001696284
REMOVAL
1. Remove the evaporator. Refer to VTL-16, "Removal and Installation".
CAUTION:
Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
2. Remove the intake sensor (1) from the evaporator (2).
CAUTION:
Mark the position of intake sensor on the evaporator for
installation.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Replace O-rings for A/C piping with new ones, and then apply compressor oil to it when installing it.
Install the intake sensor in the same position as the original intake sensor.
When recharging refrigerant, check for leaks.
ZJIA0798J
