AUTOMATIC SPEED CONTROL DEVICE (ASCD)
Component Description
INFOID:0000000001161157
1. ASCD steering switch 2. MAIN switch 3. CANCEL switch
4. SET/COAST switch 5. RESUME/ACCELERATE switch 6. ASCD brake switch
7. Stop lamp switch 8. ASCD clutch switch 9. Clutch pedal
ALBIA0273ZZ
Component Reference
ASCD steering switchEC-267, "
Description"
ASCD clutch switchEC-270, "Description"
ASCD brake switchEC-270, "Description"
ASCD indicatorEC-306, "Description"
Stop lamp switchEC-283, "Description"
Electric throttle control actuatorEC-222, "Description"
Page 1418 of 5883
CAN COMMUNICATION
EC-69
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
CAN COMMUNICATION
System DescriptionINFOID:0000000001161158
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
Refer to LAN-33, "
CAN Communication Signal Chart", about CAN communication for detail.
Page 1419 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-70
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN CONTROL
COOLING FAN CONTROL
System DiagramINFOID:0000000001161159
System DescriptionINFOID:0000000001161160
INPUT/OUTPUT SIGNAL CHART
* NISSAN TIIDA 2007 Service Repair Manual EC-70
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN CONTROL
COOLING FAN CONTROL
System DiagramINFOID:0000000001161159
System DescriptionINFOID:0000000001161160
INPUT/OUTPUT SIGNAL CHART
*](/manual-img/5/57395/w960_57395-1418.png)
EC-70
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN CONTROL
COOLING FAN CONTROL
System DiagramINFOID:0000000001161159
System DescriptionINFOID:0000000001161160
INPUT/OUTPUT SIGNAL CHART
*1: The ECM determines the start signal status by the signals of engine speed and battery voltage.
*2: This signal is sent to ECM through CAN communication line.
SYSTEM DESCRIPTION
ECM controls cooling fan speed corresponding to vehicle speed, engine coolant temperature, refrigerant pres-
sure, air conditioner ON signal. Then control system has 3-step control [HIGH/LOW/OFF].
Cooling Fan Operation
JMBIA0177GB
Sensor Input signal to ECM ECM function Actuator
Crankshaft position sensor (POS)
Camshaft position sensor (PHASE)Engine speed*
1
Cooling fan
controlIPDM E/R
↓
Cooling fan relay
↓
Cooling fan motor Battery
Battery voltage*
1
Combination meter
Vehicle speed*2
Engine coolant temperature sensor Engine coolant temperature
BCM
Air conditioner ON signal*
2
Refrigerant pressure sensor Refrigerant pressure
Page 1420 of 5883
COOLING FAN CONTROL
EC-71
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Models with A/C
Models without A/C
Cooling Fan Relay Operation
The ECM controls cooling fan relays through CAN communication line.
MBIB1451E
JMBIA0821GB
Cooling fan speedCooling fan relay
123
Stop (OFF) OFF OFF OFF
Low (LOW) ON OFF OFF
High (HI) OFF ON ON
Page 1421 of 5883
EC-72
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN CONTROL
Component Parts Location
INFOID:0000000001677956
1. Ignition coil (with power transistor)
and spark plug2. Intake valve timing control solenoid
valve3. Refrigerant pressure sensor
4. Knock sensor 5. Fuel injector 6. Cooling fan motor
7. Camshaft position sensor (PHASE) 8. IPDM E/R 9. ECM
10. Mass air flow sensor (with intake air
temperature sensor)11. Engine coolant temperature sensor 12. Electric throttle control actuator
(with built in throttle position sensor
and throttle control motor)
13. EVAP canister purge volume control
solenoid valve
PBIB2939E
Page 1422 of 5883
COOLING FAN CONTROL
EC-73
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Mass air flow sensor
(with intake air temperature sensor)2. Engine coolant temperature sensor 3. Electric throttle control actuator
4. Camshaft position sensor (PHASE) 5. Ignition coil (with power transistor) 6. Fuel injector
7. EVAP canister purge volume control
solenoid valve
Vehicle front
PBIB2940E
Page 1423 of 5883
EC-74
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN CONTROL
1. ECM harness connectors 2. ECM 3. IPDM E/R
4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid
valve6. Knock sensor
7. Refrigerant pressure sensor 8. PCV valve
Vehicle front
PBIB2941E
Page 1424 of 5883
COOLING FAN CONTROL
EC-75
< FUNCTION DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Exhaust manifold 2. Heated oxygen sensor 1 3. Heated oxygen sensor 2
