EM-154
< ON-VEHICLE REPAIR >[MR18DE]
AIR CLEANER AND AIR DUCT
AIR CLEANER AND AIR DUCT
ComponentINFOID:0000000001337782
Removal and InstallationINFOID:0000000001337783
REMOVAL
1. Remove the air duct (inlet).
2. Remove the air cleaner filter from the air cleaner case. Refer to EM-144, "
Removal and Installation".
3. Remove the air duct [between air duct (inlet) and air cleaner case] from the air cleaner case.
4. Remove the PCV hose.
5. Remove the air duct (between air cleaner case and electronic throttle control actuator).
Add marks as necessary for easier installation.
6. Remove air cleaner case with the following procedure.
a. Remove battery. Refer to PG-6, "
Removal and Installation".
b. Disconnect harness connector from mass air flow sensor.
c. Remove the air cleaner case.
7. Remove the mass air flow sensor from the air cleaner case, if necessary.
CAUTION:
Handle it carefully and avoid impacts.
Do not touch sensor part.
INSTALLATION
Installation is in the reverse order of removal.
1. Air cleaner filter 2. Holder 3. Air cleaner cover
4. Seal 5. Mass air flow sensor 6. Air duct
7. PCV hose 8. Air duct (Inlet) 9. Air duct (Front)
10. Clip 11. Resonator 12. Grommet
13. Air cleaner case A. To electronic throttle control actuator B. To rocker cover
WBIA0770E
Page 2802 of 5883
AIR CLEANER AND AIR DUCT
EM-155
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Align marks.
Attach each joint securely.
Screw clamps firmly.
Page 2803 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-156
< ON-VEHICLE REPAIR >[MR18DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
ComponentINFOID:0000000001337785
Removal and InstallationINFOID:0000000001337786
REMOVAL
1. Remove engine cover (1).
2. Drain engin NISSAN TIIDA 2007 Service Repair Manual EM-156
< ON-VEHICLE REPAIR >[MR18DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
ComponentINFOID:0000000001337785
Removal and InstallationINFOID:0000000001337786
REMOVAL
1. Remove engine cover (1).
2. Drain engin](/manual-img/5/57395/w960_57395-2802.png)
EM-156
< ON-VEHICLE REPAIR >[MR18DE]
INTAKE MANIFOLD
INTAKE MANIFOLD
ComponentINFOID:0000000001337785
Removal and InstallationINFOID:0000000001337786
REMOVAL
1. Remove engine cover (1).
2. Drain engine coolant. Refer to CO-35, "
Changing Engine Cool-
ant".
CAUTION:
Perform this step when engine is cold.
NOTE:
This step is unnecessary when putting plugs to water hoses (to
electronic throttle control actuator)
a. Disconnect water hoses from electronic throttle control actuator.
b. Remove electronic throttle control actuator.
CAUTION:
Handle carefully to avoid any shock to electronic throttle
control actuator.
Never disassemble.
3. Remove oil level gauge.
CAUTION:
Cover the oil level gauge guide openings to avoid entry of foreign materials.
1. PCV hose 2. Gasket 3. Intake manifold
4. Bracket 5. O-ring 6. EVAP canister purge volume control
solenoid valve
7. Water hose 8. Water hose 9. Electronic throttle control actuator
10. Gasket A. To water outlet
WBIA0771E
WBIA0845E
Page 2804 of 5883
INTAKE MANIFOLD
EM-157
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
4. Loosen and remove intake manifold (1) bolts (A) (B).
5. Loosen bolts in reverse order as shown.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
6. Remove EVAP canister purge volume control solenoid valve
from intake manifold, if necessary.
CAUTION:
Handle it carefully and avoid impacts.
7. Remove intake manifold.
INSTALLATION
1. Install intake manifold.
NOTE:
Be sure the intake manifold gasket is seated correctly in groove of intake manifold.
2. Tighten bolts in numerical order as shown.
: Engine front
PBIC3939E
: Engine front
PBIC3527J
: Engine front
WBIA0788E
Page 2805 of 5883
EM-158
< ON-VEHICLE REPAIR >[MR18DE]
INTAKE MANIFOLD
3. Tighten intake manifold bolt (A). Then tighten intake manifold
bolt (B).
4. Install electronic throttle control actuator
5. Install water hoses (3), (5) to electronic throttle control actuator
as shown.
6. Installation of the remaining components is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
Check for leaks of engine coolant. Refer to CO-35, "Inspection".
Start and warm up the engine. Visually check for engine coolant leaks.
1 : Intake manifold
: Engine front
PBIC3939E
1 : Electronic throttle control actuator
2: Clamp
4 : Water outlet
A: Paint Mark
B : The clamp shall not interfere with the bulged section.
C : 3 - 7 mm (0.12 - 0.28 in)
AWBIA011 5GB
Page 2806 of 5883
EXHAUST MANIFOLD
EM-159
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
EXHAUST MANIFOLD
ComponentINFOID:0000000001337787
Removal and InstallationINFOID:0000000001337788
REMOVAL
1. Remove exhaust front tube. Refer to EX-10, "Component".
2. Remove exhaust manifold cover.
3. Remove the heated oxygen sensor 1, using Tool (A).
CAUTION:
Handle it carefully and avoid impacts.
4. Remove exhaust manifold side bolt of exhaust manifold stay.
1. Exhaust manifold cover 2. Exhaust manifold 3. Gasket
4. Stud bolt 5. Bracket 6. Heated oxygen sensor 1
7. Exhaust manifold stay Engine front
WBIA0778E
Tool number :KV991J0050 (J-44626)
WBIA0772E
Page 2807 of 5883
EM-160
< ON-VEHICLE REPAIR >[MR18DE]
EXHAUST MANIFOLD
5. Loosen nuts in reverse order as shown and remove exhaust
manifold.
CAUTION:
Cover engine openings to avoid entry of foreign materials.
INSPECTION AFTER REMOVAL
Surface Distortion
Using straightedge (B) and feeler gauge (A), check the surface dis-
tortion of exhaust manifold mating surface in each exhaust port
and entire part.
If it exceeds the limit, replace exhaust manifold.
INSTALLATION
1. Install exhaust manifold gasket to cylinder head as shown.
2. Tighten exhaust manifold nuts to specification in two stages in
the numerical order as shown.
: Engine front
PBIC3529J
Limit:
Each exhaust port : 0.3 mm (0.012 in)
Entire part : 0.7 mm (0.028 in)
PBIC3530J
: Engine front
PBIC3943E
: Engine front
WBIA0854E
Page 2808 of 5883
EXHAUST MANIFOLD
EM-161
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
3. Install exhaust manifold stay (2) in the direction as shown.
4. Install the heated oxygen sensor 1, using Tool
CAUTION:
Handle it carefully and avoid impacts.
Before installing a new heated oxygen sensor, clean the
exhaust tube threads using suitable tool and approved
anti-seize lubricant.
Do not over-tighten the heated oxygen sensor. Doing so
may damage the heated oxygen sensor, resulting in the
MIL coming on.
5. Installation of the remaining parts is in the reverse order of removal.
1 : Exhaust manifold
A : Upper mark
: Engine front
PBIC3944E
Tool number : KV991J0050 (J-44626)
Tool number : — (J-43897-12)
Tool number : — (J-43897-18)
WBIA0772E
