DLK-716
< ECU DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
BCM (BODY CONTROL MODULE)
TURN SIGNAL LAMP CONTROL
BCM detects the turn signal lamp circuit status from the terminal voltage.
BCM increases the turn signal lamp blinking speed if the bulb or harness open is detected with the turn signal
lamp operating.
NOTE:
The blinking speed is normal while activating the hazard warning lamp.
DTC Inspection Priority ChartINFOID:0000000001397330
DTC IndexINFOID:0000000001397331
NOTE:
Details of time display
CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-
tion switch OFF → ON again.
PAST: Displays when there is a malfunction that is detected in the past and stored.
1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1
→ 2 → 3...38 → 39 after returning to the normal condition whenever ignition switch OFF → ON. The counter
remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch
OFF → ON after returning to the normal condition if the malfunction is detected again.
Display contents of CONSULT Fail-safe Cancellation
B2190: NATS ANTENNA AMP Inhibits engine cranking
Fuel cut (ECM)Erase DTC
B2191: DIFFERENCE OF KEY Inhibits engine cranking
Fuel cut (ECM)Erase DTC
B2192: ID DISCORD BCM-ECM Fuel cut (ECM) Erase DTC
B2193: CHAIN OF BCM-ECM Fuel cut (ECM) Erase DTC
B2194: DISCORD BCM-I-KEY Inhibits engine cranking
Fuel cut (ECM)Erase DTC
B2195: ANTI SCANNING Inhibits engine cranking
Fuel cut (ECM)Erase DTC
B2196: DONGLE NG Inhibits engine cranking
Fuel cut (ECM)Erase DTC
Priority DTC
1 U1000: CAN COMM CIRCUIT
U1010: CONTROL UNIT (CAN)
2 B2190: NATS ANTENNA AMP
B2191: DIFFERNCE OF KEY
B2192: ID DISCORD BCM-ECM
B2193: CHAIN OF BCM-ECM
B2194: DISCORD BCM-I-KEY
B2195: ANTI SCANNING
B2196: DONGLE NG
CONSULT display TIME Fail-safe Refer to
No DTC is detected.
further testing
may be required.—— — —
U1000: CAN COMM CIRCUIT 0 1 - 39 —XX-XX, "*****"
U1010: CONTROL UNIT (CAN) 0 1 - 39 —XX-XX, "*****"
B2190: NATS ANTENNA AMP CRNT PAST×XX-XX, "*****"
B2191: DIFFERENCE OF KEY CRNT PAST×XX-XX, "*****"
B2192: ID DISCORD BCM-ECM CRNT PAST×XX-XX, "*****"
Page 1306 of 5883
BCM (BODY CONTROL MODULE)
DLK-717
< ECU DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
B2193: CHAIN OF BCM-ECM CRNT PAST×XX-XX, "*****"
B2195: ANTI SCANNING CRNT PAST×XX-XX, "*****"
B2196: DONGLE NG CRNT PAST×XX-XX, "*****"
CONSULT display TIME Fail-safe Refer to
Page 1307 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-718
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK FUNCTION SYMPTOMS
SYMPTOM DIAGNOSIS
DOOR LOCK FUNCTION SYMPTOMS
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH : Sympto NISSAN TIIDA 2007 Service Repair Manual DLK-718
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK FUNCTION SYMPTOMS
SYMPTOM DIAGNOSIS
DOOR LOCK FUNCTION SYMPTOMS
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH : Sympto](/manual-img/5/57395/w960_57395-1306.png)
DLK-718
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
DOOR LOCK FUNCTION SYMPTOMS
SYMPTOM DIAGNOSIS
DOOR LOCK FUNCTION SYMPTOMS
DOOR LOCK AND UNLOCK SWITCH
DOOR LOCK AND UNLOCK SWITCH : Symptom TableINFOID:0000000001397332
DOOR LOCK AND UNLOCK SWITCH OPERATION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-610, "
Work Flow".
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
Except driver side, doors are closed.
Doors are not locked by keyfob.
Symptom Table
KEYFOB
Symptom Diagnosis/service procedure Reference page
Power door lock does not operate with door lock
and unlock switch.1. BCM Power supply and ground circuit check.BCS-30
2. Door lock and unlock switch check.DLK-61
3. Door lock actuator (driver side) checkDLK-108
4. Intermittent Incident check. GI
Specific door lock actuator does not operate.1a. Driver side door lock actuator check.DLK-108
1b. Passenger side door lock actuator check.DLK-109
1c. Rear LH side door lock actuator check.D L K - 111
1d. Rear RH side door lock actuator check.DLK-113
1e. Back door lock actuator (hatchback) check.DLK-114
2. Intermittent Incident check. GI
Specific door does not open from inside the vehicle.1a. Driver side super lock actuator check.DLK-108
1b. Passenger side super lock actuator check.DLK-109
1c. Rear LH side super lock actuator check.D L K - 111
1d. Rear RH side super lock actuator check.DLK-113
2. Intermittent Incident check. GI
Instrument panel warning lamp indicator does not
operate.1. Instrument panel warning lamp assembly check.DLK-293
2. Intermittent Incident check. GI
Key reminder function does not operate properly.1.Check “ANTI KEY LOCK IN FUNCTION” setting in
“WORK SUPPORT”.DLK-50
2a. Driver side door switch check.DLK-65
2b. Passenger side door switch check.DLK-67
2c. Rear LH side door switch check.DLK-69
2d. Rear RH side door switch check.DLK-71
2e. Back door switch (hatchback) check.DLK-73
3. Front door lock actuator LH (door unlock sensor) check.DLK-104
4. Replace BCM.BCS-57
Page 1308 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK FUNCTION SYMPTOMS
DLK-719
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEYFOB : Symptom TableINFOID:0000000001397333
KEYFOB OPERATION MALFUNCTION
NO NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK FUNCTION SYMPTOMS
DLK-719
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEYFOB : Symptom TableINFOID:0000000001397333
KEYFOB OPERATION MALFUNCTION
NO](/manual-img/5/57395/w960_57395-1307.png)
DOOR LOCK FUNCTION SYMPTOMS
DLK-719
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEYFOB : Symptom TableINFOID:0000000001397333
KEYFOB OPERATION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-610, "
Work Flow".
Check that vehicle is under the condition shown in “Conditions of Vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
Mechanical key is removed from ignition key cylinder.
Door lock and unlock operation is normal.
Symptom Table
Symptom Diagnosis/service procedureReference
page
All of the keyfob operations do not operate.1. Check keyfob battery inspection.XX-XX, "*****"
2. Check intermittent incident.XX-XX, "*****"
Anti-hijack operation does not operate.1.Check “SECURITY DOOR LOCK SET” setting in “WORK
SUPPORT”.DLK-628
2. Check Intermittent Incident.XX-XX, "*****"
Page 1309 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-720
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
BACK DOOR OPEN FUNCTION SYMPTOMS
BACK DOOR OPEN FUNCTION SYMPTOMS
BACK DOOR OPENER SWITCH
BACK DOOR OPENER SWITCH : Symptom TableINFOID:00 NISSAN TIIDA 2007 Service Repair Manual DLK-720
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
BACK DOOR OPEN FUNCTION SYMPTOMS
BACK DOOR OPEN FUNCTION SYMPTOMS
BACK DOOR OPENER SWITCH
BACK DOOR OPENER SWITCH : Symptom TableINFOID:00](/manual-img/5/57395/w960_57395-1308.png)
DLK-720
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
BACK DOOR OPEN FUNCTION SYMPTOMS
BACK DOOR OPEN FUNCTION SYMPTOMS
BACK DOOR OPENER SWITCH
BACK DOOR OPENER SWITCH : Symptom TableINFOID:0000000001397336
BACK DOOR OPENER FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-610, "
Work Flow".
Check that vehicle is under the condition shown in “Conditions of Vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
Door lock function is normal.
Vehicle speed is less than 5 km/h (3MPH).
All doors are unlocked.
Symptom Table
Symptom Diagnosis/service procedure Reference page
Back door opener function does not operate by
back door opener switch.1. Check back door opener switch.XX-XX, "*****"
2. Check vehicle speed signal.XX-XX, "*****"
3. Check back door opener actuator.XX-XX, "*****"
4. Check Intermittent Incident.XX-XX, "*****"
Page 1310 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TRUNK OPEN FUNCTION SYMPTOMS
DLK-721
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK OPEN FUNCTION SYMPTOMS
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH NISSAN TIIDA 2007 Service Repair Manual TRUNK OPEN FUNCTION SYMPTOMS
DLK-721
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK OPEN FUNCTION SYMPTOMS
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH](/manual-img/5/57395/w960_57395-1309.png)
TRUNK OPEN FUNCTION SYMPTOMS
DLK-721
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK OPEN FUNCTION SYMPTOMS
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH : Symptom TableINFOID:0000000001530719
TRUNK LID OPENER FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-16, "
Work Flow".
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
Door lock function is normal.
Vehicle speed is less than 5 km/h (3 MPH).
All doors are unlocked.
Symptom Table
Symptom Diagnosis/service procedure Reference page
Trunk lid opener function does not operate by
trunk lid opener switch.1. Check trunk lid opener switch.DLK-101
2. Check vehicle speed signal.DLK-149
3. Check trunk lid opener actuator.DLK-117
4. Check intermittent incident.XX-XX, "*****"
Trunk room lamp switch inoperative. 1. Check trunk room lamp switch.DLK-94
Page 1311 of 5883
DLK-722
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
WARNING FUNCTION SYMPTOMS
WARNING FUNCTION SYMPTOMS
BACK DOOR
BACK DOOR : Symptom TableINFOID:0000000001397337
BACK DOOR OPEN WARNING OPERATION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-610, "
Work Flow".
Check that vehicle is under the condition shown in “Conditions of Vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
Door lock function and back door opener function is normal.
Symptom Table
Symptom Diagnosis/service procedureReference
page
Back door open warning does not operate properly.1. Check back door opener switch.XX-XX, "*****"
2. Check intermittent incident.XX-XX, "*****"
Page 1312 of 5883
HAZARD REMINDER FUNCTION
DLK-723
< SYMPTOM DIAGNOSIS >[WITHOUT I-KEY, WITH SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HAZARD REMINDER FUNCTION
HAZARD WARNING LAMP
HAZARD WARNING LAMP : Symptom TableINFOID:0000000001397338
HAZARD REMINDER OPERATION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-610, "
Work Flow".
Check that vehicle is under the condition shown in “Conditions of Vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
Conditions of Vehicle (Operating Conditions)
“HAZARD LAMP SET” is ON when setting on CONSULT-III.
Door lock function is normal.
Symptom Table
Symptom Diagnosis/service procedure Reference page
Buzzer reminder operation dose not operate
properly.1.Check setting of “HAZARD LAMP SET” with CONSULT-
III.DLK-628
2. Check intermittent incident.XX-XX, "*****"
