NISSAN TIIDA 2007 Service Repair Manual SB-1
RESTRAINTS
C
D
E
F
G
I
J
K
L
M
SECTION SB
A
B
SB
N
O
P
CONTENTS
SEAT BELT
PRECAUTION ...............................................2
PRECAUTIONS .................................................
