NISSAN TIIDA 2007 Service Repair Manual EC-1100
< FUNCTION DIAGNOSIS >[K9K]
COOLING FAN CONTROL
1. Turbocharger boost control solenoid
valve2. Fuel pump 3. Turbocharger boost sensor
4. Refrigerant pressure sensor 5. EGR volume control valv

Page 2450 of 5883

NISSAN TIIDA 2007 Service Repair Manual COOLING FAN CONTROL
EC-1101
< FUNCTION DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Fuel rail pressure sensor 2. Glow relay 3. Glow plug
4. Priming pump 5. Electronic throttle control actuator

Page 2451 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1102
< FUNCTION DIAGNOSIS >[K9K]
COOLING FAN CONTROL
1. ASCD steering switch 2. ASCD switch 3. CANCEL switch
4. RESUME switch 5. SET - switch 6. SET + switch
7. Stop lamp switch 8. Brake pedal 9. A

Page 2452 of 5883

NISSAN TIIDA 2007 Service Repair Manual CAN COMMUNICATION
EC-1103
< FUNCTION DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
CAN COMMUNICATION
System DescriptionINFOID:0000000001162546
CAN (Controller Area Network) is a serial communicatio

Page 2453 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1104
< FUNCTION DIAGNOSIS >[K9K]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Diagnosis DescriptionINFOID:0000000001162547
The ECM controls the display on the instrument panel

EC-1104
< FUNCTION DIAGNOSIS >[K9K]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Diagnosis DescriptionINFOID:0000000001162547
The ECM controls the display on the instrument panel of certain information relating to the operation of the
engine.
Four functions are involved here: The OBD malfunction indicator [MI (Yellow)] for the EOBD (European On
Board Diagnostics), the pre/post heating, the engine coolant temperature and engine malfunction [MI (Red)].
These four functions are represented by four lights given out by the ECM
GLOW LAMP
This lamp indicates that the glow control system has been activated.
ENGINE COOLANT TEMPERATURE LIGHT
This light is used as an indicator of engine overheating.
In the event of overheating, it is up to the driver whether to stop the vehicle or not.
MALFUNCTION INDICATOR
The OBD malfunction indicator [MI (Yellow)] is used to alert the driver to the existence of engine control sys-
tem malfunctions involving excessive pollution or if the EOBD system is deactivated.
The ECM makes a request for lighting of the MI (Yellow) only where there is a malfunction present at the end
of three consecutive cycles.
The 3-second visual check upon powering up (automatic test procedure controlled by the IPDM E/R) is per-
formed by the ECM.
In the event of a confirmed OBD malfunction by lighting of the MI, no flashing of the light must be observed fol-
lowing the lighting test.
DTCs Causing MI to Light
ENGINE WARNING LIGHT
In the event of an engine malfunction, the ECM may request the display of an engine warning light [MI (Red)].
HOW TO ERASE DTC, 1ST TRIP DTC AND 2ND TRIP DTC
With CONSULT-III
The emission related diagnostic information in the ECM can be erased by selecting “ALL ERASE” in the
“Description” of “FINAL CHECK” mode with CONSULT-III.
MI OPERATION CHART
Some malfunction must switch on MI to warn driver, that his engine emissions exceed OBD thresholds (Euro 3
x 2.5).
The rule is to switch on MI after 3 consecutive driving cycles (engine start + engine stop + power latch) with a
present OBD malfunction.
To switch off the MI (without CONSULT-III), vehicle has to drive 3 consecutive cycles without present OBD
malfunction.
Ignition switch OFF → ON transition, MI remains switched on in pre-drive check mode until engine start.If MI
does not switch off whereas engine is running, there is at least one present OBD malfunction.
DTC Description Reference page
P0201 Cylinder 1 fuel injector control circuitEC-1142
P0202 Cylinder 2 fuel injector control circuitEC-1142
P0203 Cylinder 3 fuel injector control circuitEC-1142
P0204 Cylinder 4 fuel injector control circuitEC-1142
P0409 EGR Volume control valve control position sensor circuitEC-1158
P0606 ECMEC-1178
P2413 EGR volume control valveEC-1202

Page 2454 of 5883

NISSAN TIIDA 2007 Service Repair Manual ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-1105
< FUNCTION DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Present malfunction 2. Driving cycle counter 3. Warm up cycle counter
4. Memorised malfunction 5

Page 2455 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1106
< COMPONENT DIAGNOSIS >[K9K]
POWER SUPPLY AND GROUND CIRCUIT
COMPONENT DIAGNOSIS
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001162548
1.INSPECTION START
Start engine.
Is

Page 2456 of 5883

NISSAN TIIDA 2007 Service Repair Manual POWER SUPPLY AND GROUND CIRCUIT
EC-1107
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
>> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK ECM P
