Page 3089 of 5267
14. Remove separator plate (1) from transfer plate
(2).
15. Remove the oil screen (1)from the transfer plate.
16. Remove thermal valve (1) from transfer plate.
Page 3090 of 5267
17. Remove valve body check balls (1-4). Note their location for assembly ease.
18. Remove 2/4 accumulator assembly (1-5).
Ball Check Location
1 - (#4) BALL CHECK LOCATION
2 - (#2) BALL CHECK LOCATION
3 - (#5) BALL CHECK LOCATION
4 - (#3) BALL CHECK LOCATION
Page 3091 of 5267
19. Remove dual retainer plate (2) from valve body.
Use Remover/Installer 6301 (1) to remove plate
(2).
20. Remove regulator valve spring retainer (2).
21. Remove remaining retainers (1, 2).
Page 3092 of 5267
22. Remove all valves and springs.
23. Cleanliness through entire disassembly and assembly of the valve bodycannot be overemphasized. When dis-
assembling, each part should be washed in a suitable solvent, then dried bycompressed air.Do not wipe
parts with shop towels.All mating surfaces in the valve body are accurately machined; therefore,careful han-
dling of all parts must be exercised to avoid nicks or burrs.
ASSEMBLY
NOTE: If the valve body assembly is being reconditioned or replaced, it is necessary to perform the Quick
Learn Procedure using the scan tool. (Refer to 8 - ELECTRICAL/ELECTRONIC CONTROL MODULES/TRANS-
MISSION CONTROL MODULE - STANDARD PROCEDURE)
Valve Body Assembly
1-VALVEBODY
2 - T / C R E G U L AT O R VA LV E
3-L/RSWITCHVALVE
4 - CONVERTER CLUTCH CONTROL VALVE
5 - MANUAL VALVE
6 - CONVERTER CLUTCH SWITCH VALVE
7 - SOLENOID SWITCH VALVE
8 - REGULATOR VALVE
Page 3093 of 5267
1. Install all valves and springs as shown.
2. Install regulator valve spring retainer (2).
Valve Body Assembly
1-VALVEBODY
2 - T / C R E G U L AT O R VA LV E
3-L/RSWITCHVALVE
4 - CONVERTER CLUTCH CONTROL VALVE
5 - MANUAL VALVE
6 - CONVERTER CLUTCH SWITCH VALVE
7 - SOLENOID SWITCH VALVE
8 - REGULATOR VALVE
Page 3094 of 5267
3. Install dual retainer plate (2) using Remover/In-
staller 6301 (1).
4. Verify that all retainers (1, 2) are installed as
shown. Retainers should be flush or below valve
body surface.
5. Install 2/4 Accumulator components (1-5) as
shown. Torque 2/4 Accumulator retainer plate to 5
Nꞏm (45 in. lbs.).
Page 3095 of 5267
6. Install check balls into position as shown. If necessary, secure them with petrolatum or transmission assembly
gel for assembly ease.
7. Install thermal valve (1) to the transfer plate.
Ball Check Location
1 - (#4) BALL CHECK LOCATION
2 - (#2) BALL CHECK LOCATION
3 - (#5) BALL CHECK LOCATION
4 - (#3) BALL CHECK LOCATION
Page 3096 of 5267
8. Install the oil screen (1) to the transfer plate.
9. Install separator plate (1) to transfer plate (2).
10. Install the two separator plate-to-transfer plate
screws (2).
