Page 4585 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SEAT BACK CUSHION / COVER - REAR REMOVAL 1. Remove the rear seat back. (Refer to23 - BODY/SEATS/SEAT BACK - REAR - REMOVAL) 2. Remove the headrest sleeves. (Refer to 23 - BODY/SEATS/HEADREST SLEEVE- R

Page 4586 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SEAT CUSHION / COVER - REAR REMOVAL 1. Remove the rear seat. (Refer to 23- BODY/SEATS/SEAT - REAR - REMOVAL) 2. Separate the zip strip at the rear of the seat cushion and remove the cushion and cover.

Page 4587 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SEAT CUSHION FRAME - REAR REMOVAL 1. Remove the seat cushion/cover (Refer to 23 - BODY/SEATS/SEAT CUSHION/COVER - REAR - REMOVAL). 2. Remove the bolts (3) and remove the seat cushion frame (2). INSTAL

Page 4588 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual UNDER SEAT STORAGE BIN LID REMOVAL NOTE: Do not reuse the seat fasteners, always replace with new ones. 1. Open the center seat cushion/storage bin. 2. Position the seat cushion cover aside, remove th

Page 4589 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual UNDER SEAT STORAGE BIN REMOVAL 1. Remove the amplifier, if equipped.(Refer to 8 - ELECTRICAL/AUDIO/AMPLIFIER - REMOVAL) 2. Remove the center seat cushion. (Refer to 23 - BODY/SEATS/CENTER SEAT CUSHION

Page 4590 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual UNDER SEAT STORAGE BIN COVERING REMOVAL 1. Remove the under seat storage bin. (Refer to 23 - BODY/SEATS/UNDER SEAT STORAGE BIN - REMOVAL) 2. Disconnect the j-straps and remove the cover. INSTALLATION

Page 4591 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual UNDER SEAT STORAGE BIN LATCH REMOVAL 1. Open the under seat storage bin. 2. Remove the two screws and remove the latch assembly. INSTALLATION 1. Install the latch assembly and install the screws.

Page 4592 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SEAT BACK REAR - FOOTMANS LOOP BRACKETS REMOVAL 1. Remove the rear seat (Refer to 23 - BODY/SEATS/ SEAT - REAR - REMOVAL). 2. Remove bolts (2) and remove the loop (1). INSTALLATION 1. Install the loop
