Page 4489 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 16. Remove the two bolts (1) that secure the instru- ment panel to the center of the floor panel. 17. Remove the right cowl trim cover (Refer to 23 - BODY/INTERIOR/COWL TRIM - REMOVAL). 18. Disconnect

Page 4490 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 19. Disconnect the antenna coaxial cable connector (1) from the radio coaxial cable connector (2) located on the right side of the cowl panel. 20. Remove the one bolt (2) that secures the instru- ment

Page 4491 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 21. Remove the right a-pillar trim (Refer to 23 - BODY/INTERIOR/A-PILLAR TRIM/GRAB HAN- DLE - REMOVAL). 22. Using a trim stick C-4755 or equivalent, from the notch on the bottom, remove the right inst

Page 4492 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 23. Remove the three bolts (1) that secure the right side instrument panel bracket to the dash panel. 24. Remove the four screws (2) that secure the instrument panel (5) to the top of the cowl panel (

Page 4493 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Install the three bolts (1) that secure the right side instrument panel bracket to the cowl panel. 8. Tighten the bolts to 12 Nꞏm (9 ft. lbs.). 9. Install the right a-pillar trim (Refer to 23 - B

Page 4494 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 12. Connect the radio coaxial cable connector (2) to the antenna coaxial cable connector (1) located on the right side of the cowl panel. 13. Connect the two instrument panel wire harness connectors t

Page 4495 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 14. Install the right cowl trim panel (Refer to 23 - BODY/INTERIOR/COWL TRIM - INSTALLATION). 15. Install the two bolts (1) that secure the instrument panel to the center of the floor panel. 16. Tight

Page 4496 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 19. Install the floor console, if equipped (Refer to 23 - BODY/INTERIOR/FLOOR CONSOLE - INSTALLATION). 20. Install the three bolts (1) that secure the left side of the instrument panel to the dash pan
