Page 2929 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Remove the adapter (2) housing, 4X4 vehicles only, from the transmission case. There are two pry slots located near the bottom corners of the hous- ing for separating the housing from the transmis-

Page 2930 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual a. Remove the extension shaft bearing snap ring (3) from the extension housing. b. Remove the extension shaft and bearing assembly (2) from the extension housing (1). c. Remove the extension shaft bea

Page 2931 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual d. Remove the extension shaft bearing (2) from the extension shaft (1). 9. UsingaSlideHammerC-3752(2),removethe4X4 stub shaft (1). 10. Remove the 4X4 stub shaft (1) from the transmis- sion output shaf

Page 2932 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual NOTE: The speed sensor bolts have a sealing patch applied from the factory. Separate these bolts for reuse. 11. Remove the input speed sensor bolt. NOTE: The speed sensor bolts have a sealing patch ap

Page 2933 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual NOTE: One of the oil pan bolts has a sealing patch applied from the factory. Separate this bolt for reuse. 14. Remove the transmission oil pan bolts (2). 15. Removethetransmissionoilpan(1). 16. Remove

Page 2934 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 17. Remove transmission oil filter (1). 18. Remove the oil filter o-ring (2) from the valve body. 19. Remove valve body-to-case bolts (1).

Page 2935 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CAUTION: Do not handle the valve body by the manual shaft. Damage could result. 20. Remove valve body (1) from transmission. 21. Remove underdrive and overdrive accumulators (1, 2). 22. Remove the low

Page 2936 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 23. Remove the low/reverse accumulator plug (2). 24. Remove low/reverse accumulator piston (1) using suitable pliers. 25. Remove piston (1) and springs (2).
