Page 2513 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual RETURN HOSE - GEAR TO COOLER NOTE: Before installing power steering hose, replace used O-rings as necessary. Clean hose ends, fittings and open ports with a lint-free cloth. Lubricate O-rings with cle

Page 2514 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual RESERVOIR REMOVAL 1. Remove power steering pump from vehicle. (Refer to 19 - STEERING/PUMP - REMOVAL) 2. Clean exterior of pump. 3. Clamp pump body in a soft jaw vice. NOTE: Use new retaining clips fo

Page 2515 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual PULLEY REMOVAL 1. Remove the power steering pump assembly (1), (Refer to 19 - STEERING/PUMP - REMOVAL). 2. Remove the pulley (2) from the pump using (OTC 7185) power steering pulley removal tool or eq

Page 2516 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual FLUID COOLER TUBE REMOVAL 1. Drain and siphon the power steering fluid. 2. Remove the underneath splash shield. 3. Disconnect the quick connect power steering fluid cooler tubes (3) from the fluid coo

Page 2517 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Remove the tube retaining bracket (4) and then the fluid cooler tubes (2). INSTALLATION 1. Reconnect the quick connect fittings (2) to the return and supply tubes (3) to the power steering fluid co

Page 2518 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual FLUID COOLER REMOVAL 1. Drain and siphon the power steering fluid. 2. Remove the underneath splash shield. 3. Remove the two bolts (2) from the air deflector (4) between the bumper (3) and A/C condens

Page 2519 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Remove the mounting bracket bolts (1) securing the fluid cooler (3) to the brace. 7. Remove the fluid cooler (1) from the vehicle. NOTE: If needed disconnect the power steering fluid cooler hoses (

Page 2520 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Install the fluid cooler (1) to the vehicle. 2. Install the mounting bracket bolts (1) securing the fluid cooler (3) to the brace.
