DODGE RAM SRT-10 2006  Service Repair Manual P1411–CYLINDER 1 REACTIVATION CONTROL PERFORMANCE

Page 98 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual For a complete wiring diagramRefer to Section 8W.
Theory of Operation
When all criteria has been met, power is supplied to each MDS Solenoid when the engine is making a transition
from 8 cylinder mode

Page 99 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 2.MDS SOLENOID NO.1
Turn the ignition off.
Gain access to the MDS Solenoid No.1.
Disconnect the MDS Solenoid No.1 harness connector.
Ignition on, engine not running.
Turn off all accessories.
Using a

Page 100 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 4.(K451) MDS SOLENOID NO.1 CONTROL CIRCUIT SHORTED TO GROUND
Disconnect the C3 PCM harness connector.
Measure the resistance between ground and the (K451) MDS Solenoid
No.1 Control circuit in the MDS

Page 101 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 6.PCM
NOTE: Before continuing, check the PCM harness connector terminals for corrosion, damage, or terminal
push out. Repair as necessary.
Using the schematics as a guide, inspect the wire harness and

Page 102 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual P1414–CYLINDER 4 REACTIVATION CONTROL PERFORMANCE

Page 103 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual For a complete wiring diagramRefer to Section 8W.
Theory of Operation
When all criteria has been met, power is supplied to each MDS Solenoid when the engine is making a transition
from 8 cylinder mode

Page 104 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 2.MDS SOLENOID NO.4
Turn the ignition off.
Gain access to the MDS Solenoid No.4.
Disconnect the MDS Solenoid No.4 harness connector.
Ignition on, engine not running.
Turn off all accessories.
Using a
