DODGE RAM SRT-10 2006 Service Repair Manual C1407- TRANSFER CASE BRAKE CONTROL CIRCUIT LOW
For a complete wiring diagramRefer to Section 8W

Page 4042 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored:
With the ignition on and no system undervoltage or overvoltage condition present.
Set Condition:
The Totally Integrated Power Module (TIPM) detects that the Transfer CaseBrake circuit

Page 4043 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.ACTUATE T-CASE MOTOR
Reconnect the TIPM C4 harness connector.
Ignition on, engine not running.
With the scan tool, actuate the T-Case Motor Brake.
Using a 12-volt test light connected to 12-volts, c

3.ACTUATE T-CASE MOTOR
Reconnect the TIPM C4 harness connector.
Ignition on, engine not running.
With the scan tool, actuate the T-Case Motor Brake.
Using a 12-volt test light connected to 12-volts, check the (T300) Trans-
fer Case Motor Brake Signal circuit at the Shift Motor/Mode Sensor
Assembly harness connector.
NOTE: Compare the brightness to that of a direct connection to
the battery.
Does the test light illuminate brightly?
Ye s>>
Replace the Totally Integrated Power Module (TIPM) in
accordance with the Service Information.
Perform the TRANSFER CASE VERIFICATION TEST-VER
1. (Refer to 21 - TRANSMISSION/TRANSAXLE/TRANSFER
CASE - STANDARD PROCEDURE)
No>>
Go to 4
4.(T300) TRANSFER CASE MOTOR BRAKE SIGNAL CIRCUIT OPEN
Turn the ignition off to the lock position.
Disconnect the TIPM C4 harness connector.
Measure the resistance of the (T300) Transfer Case Motor Brake Signal
circuit between the TIPM C4 harness connector and the Shift Motor/
Mode Sensor Assembly harness connector.
Is the resistance above 5.0 ohms?
Ye s>>
Repair the (T300) Transfer Case Motor Brake Signal circuit
for an open circuit or high resistance.
Perform the TRANSFER CASE VERIFICATION TEST-VER
1. (Refer to 21 - TRANSMISSION/TRANSAXLE/TRANSFER
CASE - STANDARD PROCEDURE)
No>>
Replace the Totally Integrated Power Module (TIPM) in
accordance with the Service Information.
Perform the TRANSFER CASE VERIFICATION TEST-VER
1. (Refer to 21 - TRANSMISSION/TRANSAXLE/TRANSFER
CASE - STANDARD PROCEDURE)
5.INTERMITTENT WIRING AND CONNECTORS
The conditions necessary to set this DTC are not present at this time.
Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
While monitoring the scan tool data relative to this circuit, wiggle test the wiring and connectors.
Look for the data to change or for the DTC to reset during the wiggle test.
Were any problems found?
Ye s>>
Repair as necessary.
Perform the TRANSFER CASE VERIFICATION TEST-VER 1. (Refer to 21 - TRANSMISSION/TRANS-
AXLE/TRANSFER CASE - STANDARD PROCEDURE)
No>>
Te s t c o m p l e t e .

Page 4044 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual C1408-TRANSFER CASE BRAKE CONTROL CIRCUIT HIGH
For a complete wiring diagramRefer to Section 8W

Page 4045 of 5267

Page 4046 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.(T300) TRANSFER CASE MOTOR LOCK SIGNAL CIRCUIT SHORTED TO THE (A918) FUSEDBATTERY
SUPPLY CIRCUIT
Measure the resistance between the (T300) Transfer Case Motor Brake
Signal circuit and the (A918) Fus

Page 4047 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual C140B- TRANSFER CASE MOTOR CONTROL CIRCUIT LOW
For a complete wiring diagramRefer to Section 8W

Page 4048 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored:
Ignition on. Battery voltage between 9.0 and 16.0 volts.
Set Condition:
Totally Integrated Power Module (TIPM) detects low voltage on the Transfer Case Motor Control circuit for a
peri
