DODGE RAM SRT-10 2006 Service Repair Manual 24. Install reverse gear synchronizer hub (1) with snap ring (2) on the top on mainshaft. 25. Heat mainshaft bearing (1) on bearing heater (2) to a maximum of 177 Celsius (350° Fahrenheit). 26. Using

Page 2562 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 28. Install reverse synchronizer hub (1) detents (2). 29. Install reverse gear (2) synchronizer sleeve (1) on hub and center sleeve on hub. 30. Turn mainshaft and Fixture 9605 over and secure in vise.

Page 2563 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 32. Install third gear (1) on mainshaft (2). 33. Install third gear stop ring (1) with teeth pointing up on third gear (2). 34. Install third gear inner friction ring (1) on stop ring (2).

Page 2564 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 35. Install third gear outer friction ring (1) on stop ring (2). 36. Install third gear blocker ring (1) on stop ring (2). 37. Install 3-4 synchronizer hub (1) on third gear syn- chronizer rings (2).

Page 2565 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 38. Install third gear synchronizer hub (1) snap ring (2). 39. Install 3-4 synchronizer sleeve (3) on hub (2) and push sleeve to the bottom of the hub. NOTE: 3-4 synchronizer sleeve (3) and hub (2) ha

Page 2566 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 42. Install fourth gear outer friction ring (1) on syn- chronizer hub (2). 43. Install fourth gear inner friction ring (1) on syn- chronizer hub (2). 44. Install fourth gear stop ring (1) with teeth p

Page 2567 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 46. Install fourth gear (1) and bearing (2). 47. Heat fourth gear thrust washer (1) on bearing heater (2) to a maximum of 177 Celsius (350° Fahrenheit). 48. Using welding gloves or tongs, install fou

Page 2568 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 49. Install fourth gear (1) snap ring (2). 50. Install sixth gear (1) and bearing (2) on mainshaft (3). 51. Install sixth gear stop ring (1) on sixth gear (2).
