Page 1249 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0353-IGNITION COIL #3 PRIMARY CIRCUIT For a complete wiring diagramRefer to Section 8W.

Page 1250 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With battery voltage greater than 8 volts during engine cranking or greater than 12 volts with engine running, engine rpm less than 2016, and none of the coils in dwell when checked. S

Page 1251 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.IGNITION COIL RESISTANCE Turn the ignition off. The resistance of a 8.3L Primary Ignition coil is 0.53 to 0.65 of an ohm. Measure the resistance of the primary Ignition coil. Is the resistance withi

Page 1252 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6.(K18) IGNITION COIL CONTROL NO.3 CIRCUIT OPEN Turn the ignition off. Disconnect the C1 PCM harness connector. Measure the resistance of the (K18) Ignition Coil Control No.3 circuit from the Ignition

Page 1253 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0354-IGNITION COIL #4 PRIMARY CIRCUIT For a complete wiring diagramRefer to Section 8W.

Page 1254 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With battery voltage greater than 8 volts during engine cranking or greater than 12 volts with engine running, engine rpm less than 2016, and none of the coils in dwell when checked. S

Page 1255 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.IGNITION COIL RESISTANCE Turn the ignition off. The resistance of a 8.3L Primary Ignition coil is 0.53 to 0.65 of an ohm. Measure the resistance of the primary Ignition coil. Is the resistance withi

Page 1256 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6.(K133) IGNITION COIL CONTROL NO.4 CIRCUIT OPEN Turn the ignition off. Disconnect the C1 PCM harness connector. Measure the resistance of the (K133) Ignition Coil Control No.4 circuit from the Igniti
