Page 2609 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 41. Remove 3-4 (2) and 5-6 (1) shift fork pivot bolts from both sides of the front housing. 42. Install Puller 9621(1) with puller Plug 9621-2 (2) on front housing. Tighten puller bolts evenly and rem

Page 2610 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 43. Remove 5-6 shift fork (3) and 3-4 shift fork (4). Then remove 5-6 shift rail (1) and 3-4 shift rail (2) from Fixture 9626. 44. Remove input shaft (1) from mainshaft (2).

Page 2611 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 45. Remove input shaft bearing (1) from mainshaft (2). 46. Remove countershaft (2) from fixture (3).

Page 2612 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual MAINSHAFT 1. Remove fifth gear synchronizer clutch body (1) from 5-6 synchronizer hub (2). 2. Remove fifth gear synchronizer friction ring (1) from 5-6 synchronizer hub (2).

Page 2613 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Remove 5-6 synchronizer sleeve (1) from hub (2). 4. Remove 5-6 synchronizer detents (1) from hub (2). 5. Remove 5-6 synchronizer hub (1) snap ring (2).

Page 2614 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Remove 5-6 synchronizer hub (1) with three jaw puller (2) and Button 9618-2 (3). Position jaws under sixth gear clutch body (4). 7. Remove sixth gear (1) from mainshaft (2).

Page 2615 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8. Remove sixth gear bearing (1) from mainshaft (2). 9. Remove mainshaft center support bearing (1) from mainshaft (2).

Page 2616 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual COUNTERSHAFT 1. Remove countershaft center support bearing (1) from counter shaft (2). NOTE: Countershaft with 3-4 synchronizer, is ser- viced as an assembly except bearings. CENTER SUPPORT PLATE 1. R
