Page 185 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P2098-DOWNSTREAM FUEL TRIM SYSTEM 2 LEAN For a complete wiring diagramRefer to Section 8W.

Page 186 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With the engine running in closed loop mode, the ambient/battery temperature above (-7°C) 20°F, altitude below 8500 ft and fuel level greater than 15%. Set Condition: If the PCM mult

Page 187 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.ENGINE MECHANICAL Check for any of the following conditions/mechanical problems. AIR INDUCTION SYSTEM - must be free from leaks ENGINE VACUUM - must be at least 13 inches in neutral ENGINE VALVE TIM

Page 188 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5.(K243) O2 SENSOR 2/2 SIGNAL CIRCUIT Remove the jump wire. Ignition on, engine not running. With the scan tool, monitor the O2 Sensor voltage. Is the voltage above 4.8 volts? Ye s>> Go To 6 No>> Chec

Page 189 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7.(K904) O2 RETURN DOWNSTREAM CIRCUIT Measure the voltage on the (K904) O2 Return Downstream circuit in the O2 Sensor harness connector. Is the voltage at 2.5 volts? Ye s>> Check the fuel system for c

Page 190 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P2099-DOWNSTREAM FUEL TRIM SYSTEM 2 RICH For a complete wiring diagramRefer to Section 8W.

Page 191 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With the engine running in closed loop mode, the ambient/battery temperature above (-7°C) 20°F, altitude below 8500 ft. Set Condition: If the PCM multiplies short term compensation b

Page 192 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.ENGINE MECHANICAL Check for any of the following conditions/mechanical problems. AIR INDUCTION SYSTEM - must be free from leaks ENGINE VACUUM - must be at least 13 inches in neutral ENGINE VALVE TIM
