48. Use Wrench 6497 (1) and Wrench 6498A (2) to
remove the output shaft nut.
49. Remove the output shaft (1) from case (3) using a
shop press (2).
50. Use Remover 6596 (2) with a shop press (1) to
remove the front output shaft bearing cup.
Page 2946 of 5267
51. Use Remover 6597 (2) and Universal Handle
C-4171 (1) and Handle Extension C-4171-2 to
press the rear output shaft bearing cup rearward.
52. Remove the rear carrier front bearing cone (3).
Page 2947 of 5267
53. Install and load compressor 5059A (4) as shown.
54. Remove the low/reverse belleville spring snap ring
(1).
55. Remove the low/reverse piston belleville spring
(1).
Page 2948 of 5267
56. Remove the park sprag pivot retaining screw.
57. Drive out the anchor shaft using suitable punch
(1).
58. Remove the guide bracket pivot pin (1). Inspect
all components for wear and replace if necessary.
NOTE: The Low/Reverse Clutch Piston has bonded
seals which are not individually serviceable. Seal
replacement requires replacement of the piston
assembly.
59. Remove the low/reverse clutch piston (1).
60. Remove the low/reverse piston retainer screws.
Page 2949 of 5267
61. Remove low/reverse piston retainer (1).
62. Remove the low/reverse piston retainer gasket
(2).
ASSEMBLY
NOTE: If the transmission assembly is being reconditioned (clutch/seal replacement) or replaced, it is nec-
essary to perform the Quick Learn Procedure using the scan tool (Refer to 8 -ELECTRICAL/ELECTRONIC
CONTROL MODULES/TRANSMISSION CONTROL MODULE - STANDARD PROCEDURE).
1. Install the output bearing cups using Installer
5050A.
Page 2950 of 5267
2. Install low/reverse piston retainer gasket (2).
3. Install low/reverse piston retainer (1).
4. Install low/reverse piston retainer-to-case screws
(3) and torque to 5 Nꞏm (45 in. lbs.).
Page 2951 of 5267
NOTE: The Low/Reverse Clutch Piston has bonded
seals which are not individually serviceable. Seal
replacement requires replacement of the piston
assembly.
5. Install low/reverse clutch piston (1).
6. Assemble guide bracket (1) assembly as shown, if
necessary.
CAUTION: When installing, be sure guide bracket
and split sleeve touch the rear of the transmission
case.
7. Install guide bracket pivot pin (1).
8. Install park sprag pivot retaining bolt and torque to
4.5 Nꞏm (40 in. lbs.).
Page 2952 of 5267
9. Install low/reverse piston belleville spring (1) into
position.
10. Install and load low/reverse spring compressor
tools (Compressors 5058A-3 and 5059A and Disk
6057) (3, 4, 5) as shown to facilitate snap ring (2)
installation.
11. Install snap ring (1) and remove the tools.
