DODGE RAM SRT-10 2006 Service Repair Manual 6. Press second gear (3) and synchronizer (2) hub off mainshaft (1) with Splitter 9375 (4). 7. Remove 3-4 synchronizer (1) snap ring (2).

Page 2682 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8. Press third gear (1), 3-4 synchronizer (2) hub and sleeve off mainshaft with Splitter 9375 (3). 9. Remove third gear bearing (2) and spacer (1) from mainshaft. 10. Remove mainshaft tapered bearing

Page 2683 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual COUNTERSHAFT 1. Remove countershaft adapter plate bearing (2) with Splitter 9388 (1) and Press Adapter 9377 (3). 2. Remove countershaft (1) housing bearing (2) with Splitter 9384 (3) and a press.

Page 2684 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INPUT SHAFT 1. Remove input shaft (1) bearing (2) with Splitter 9384 (3) and a press. 2. Remove input shaft bearing cup (2) with Remover 9381 (1) and Slide Hammer C-3752.

Page 2685 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual EXTENSION HOUSING 1. Remove idler gear bracket bolts (2) and bracket. 2. Remove thrust washer, gear (3) and bearing (2) from tail housing (1). 3. Remove gear shaft.

Page 2686 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Remove mainshaft bearing race (1) snap ring (2). 5. Remove mainshaft race (2) with Remove 7794-A (1) and Slide Hammer C-637. 6. Remove countershaft bearing plastic bearing cage (2) and remove rolle

Page 2687 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Remove countershaft bearing race (1) with Remover 9395 (2) and Slide Hammer C-637. 8. Remove shift rail bushings with Remover 9367 (1) and Slide Hammer C-3752 (2).

Page 2688 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual TRANSMISSION CASE 1. Remove shift rail bushings with Remover 9367 and Slide Hammer C-3752. 39. Remove countershaft bearing cups with Remover 9369 (1) and Handle C-4171(2). 40. Remove mainshaft bearing
