Page 481 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5.(K690) RETURN CIRCUIT OPEN Measure the resistance of the sensor (K690) return circuit between the sensor harness connector and the ECM harness connector. Is the resistance less than 10 Ohms? Ye s>>

Page 482 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7.ECM Reconnect the ECM harness connector. Turn the ignition on. With the scan tool, erase DTCs. While monitoring with scan tool, use a jumper wire and connect the sensor (K615) signal circuit to the

Page 483 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0088-FUEL RAIL PRESSURE SIGNAL IS ABOVE MAX LIMIT For a complete wiring diagramRefer to Section 8W.

Page 484 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: Engine running. Set Condition: Fuel pressure is above a calibrated value for a calibrated amount of time. Possible Causes FUEL CONTROL ACTUATOR (FCA) FUEL PRESSURE SENSOR INTERMITTENT

Page 485 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0106-INLET AIR PRESSURE SENSOR RATIONALITY For a complete wiring diagramRefer to Section 8W.

Page 486 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: When the ignition is on. Set Condition: The Inlet air pressure is above a calibrated threshold. Possible Causes INLET AIR PRESSURE SENSOR INTERMITTENT CONDITION TROUBLESHOOT OTHER DTC

Page 487 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0107-INLET AIR PRESSURE SENSOR VOLTAGE TOO LOW For a complete wiring diagramRefer to Section 8W.

Page 488 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With the ignition on and battery voltage greater than 10.4 volts. Set Condition: The circuit voltage to the ECM falls below a calibrated threshold for a certain period of time. Possibl
