DODGE RAM SRT-10 2006 Service Repair Manual P2174-LOW AIRFLOW/RESTRICTION DETECTED (INSTANTANEOUS ACCUMULATION)

Page 290 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual For a complete wiring diagramRefer to Section 8W. When Monitored: Ignition on and engine running with no MAP Sensor DTCs. Set Condition: PCM calculated MAP value is greater than actual MAP value plus

Page 291 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2.RESTRICTED AIR INLET SYSTEM Turn the ignition off. Remove the Air Cleaner Assembly. Remove the Air Filter. Inspect the Throttle Body opening for signs of any foreign materials. Check the intake tube

Page 292 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5.RESISTANCE IN THE (F855) 5-VOLT SUPPLY CIRCUIT Turn the ignition off. Disconnect the Throttle Body harness connector. Disconnect the C2 PCM harness connector. CAUTION: Do not probe the PCM harness c

Page 293 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7.TP SENSOR Connect the PCM harness connectors. Ignition on, engine not running. With a scan tool, monitor the TP Sensor voltage. Connect a jumper wire between the (K22) TP Sensor No.1 Signal circuit

Page 294 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 9.TP SENSOR SIGNAL CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (K22) and (K122) TP Signal circuits at the Throttle Body harness connector. Is the resistance above 100k ohms

Page 295 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 10.RESISTANCE IN (K922) TP SENSOR RETURN CIRCUIT Measure the resistance of the (K922) TP Sensor Return circuit from the Throttle Body harness connector to the appropriate terminal of special tool #881

Page 296 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 12.(F856) 5-VOLT SUPPLY CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (F856) 5-volt Supply circuit in the MAP Sensor harness connector. Is the resistance above 100k ohms? Ye
