Page 2665 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual REMOVAL 1. With vehicle in neutral, position it on a hoist. 2. Mark installation reference marks on the propeller shaft, pinion yoke and transmission output shaft. 3. Remove propeller shaft (4) clamp

Page 2666 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Remove reverse lockout solenoid (1) connector (2). 7. Remove fuel line clipfrom top plate stud. 8. Remove back up lamp switch (2) connector (1). 9. Position transmission jack (2) and secure to tran

Page 2667 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 11. Remove transmission mount (2) bolts (1). 12. Remove transmission crossmember (2) bolts (1). 13. Slide transmission back to clear the bell housing. Then lower transmission. DISASSEMBLY 1. Remove sh

Page 2668 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Remove offset lever (1) from tail housing (2). . 4. Remove two tail housing nuts (2) from top of the transmission tail housing (3). 5. Remove six tail housing (1) bolts (2).

Page 2669 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Pry tail housing (1) off case at pry points (2) (4) only. 7. Remove mainshaft (3) roller bearing snap ring, roller bearing (4) and spacers (2). 8. Remove reverse gear (1) snap ring (4) and thrust w

Page 2670 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 9. Remove reverse gear (3), bearing (5), wave washer (2) and brass reverse blocker ring (1) from mainshaft (4). 10. Tap reverse synchronizer (3) on mainshaft (2) to relieve pressure on snap ring and r

Page 2671 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 12. Remove reverse synchronizer (1) sleeve snap ring (2). 13. Remove shift fork (1) and synchronizer (2) sleeve as an assembly. 14. Remove 5-6 gear shift fork (1) snap ring (2).

Page 2672 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 15. Remove reverse gear (1) from countershaft with three jaw puller (2). 16. Remove fifth gear (1) snap ring (2) from countershaft. 17. Remove fifth gear (1) thrust washer (2) from countershaft.
