Page 2041 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CYLINDER BLOCK DESCRIPTIONSPECIFICATION Metric Standard Cylinder Bore Diameter 102.356-102.368 mm 4.02975-4.03025 in. Out of Round (Max.) 0.051 mm 0.002 in. Taper (Max.) 0.038 mm 0.0015 in. Tappet Bor

Page 2042 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DESCRIPTIONSPECIFICATION Metric Standard Piston Size 102.314-102.332 mm. 4.0281-4.0288 in. Clearance at Top of Skirt (12 mm from bottom)0.025-0.055 mm. 0.0010-0.0022 in. Land Clearance (Diametrical) 0

Page 2043 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DESCRIPTIONSPECIFICATION Metric Standard Lift 8.13 mm 0.320 in. Journal Diameter 1-6 53.09-53.11 mm 2.090-2.091 in. Boar Diameter No.1-6 53.16-53.19 mm 2.093-2.094 in. Diametrical Clearance 0.051-0.10

Page 2044 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DESCRIPTIONSPECIFICATION Metric Standard Face Angle 45-45.5° Back Cut Angle 25°-29° Stem Diameter-Intake and Exhaust 7.90-7.92 mm 0.331-0.312 in. Head Diameter-Intake 50.67-50.93 mm 1.995-2.005 in.

Page 2045 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DESCRIPTIONSPECIFICATION Metric Standard Clearance Over Rotors (Max.) 0.077 mm 0.003 in. Cover Out-Of-Flat (Max.) 0.076 mm 0.003 in. Inner Rotor Thickness (Min.) 18.92 mm 0.744 in. Clearance (Max.) 0.

Page 2046 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual DESCRIPTION Nꞏm Ft. Lbs. In. Lbs. Oil Filter18 - 160 Oil Pressure Sensor 8.5 - 75 Oil Temperature Sensor 8.5 - 75 Bolts-Power Steering Pump Mounting 23 - 200 Bolts-Rear Crankshaft Seal Retainer 11 -

Page 2047 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SPECIAL TOOLS ENGINE Crankshaft Insert 8194 Crankshaft Damper/Sprocket Installer 9055 Crankshaft Sprocket Remover 9056 Puller 5048 Bearing/Seal Remover Adapter - 8990 Puller, Slide Hammer C-3752 Crank

Page 2048 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Front Crankshaft Seal Remover C-4679A Front Crankshaft Seal Installer MD-998306 Rear Crankshaft Seal Installation Guide 9060 Valve Spring Compressor MD998772A Valve Spring Tester C-647 Pressure Tester
