11. Remove the upper radiator crossmember (4). (Refer to 23 - BODY/EXTERIOR/UPPER RADIATOR CROSS-
MEMBER - REMOVAL).
12. Remove the headlamp unit (5) (Refer to 8 -
ELECTRICAL/LAMPS/LIGHTING - EXTERIOR/
HEADLAMP UNIT - REMOVAL).

27. Install the front cab mount bolt (2) if previously removed and tighten to81Nꞏm(60ft.lbs.).
28. Install the lower radiator crossmember (6) bolts (5) and tighten to 28 Nꞏm ( 2 1 f t . l b s . ) .
29. Install the headlamp unit (Refer to 8 - ELECTRI-
CAL/LAMPS/LIGHTING - EXTERIOR/HEADLAMP
UNIT - INSTALLATION).

FRONT FENDER
REMOVAL
1. Remove the radio antenna (Refer to 8 - ELECTRI-
CAL/AUDIO/ANTENNA BODY & CABLE -
REMOVAL).
2. Remove the battery tray (depending on fender
beingserviced)(Referto8-ELECTRICAL/BAT-
TERY SYSTEM/TRAY - REMOVAL).
3. Remove the cowl grille (Refer to 23 - BODY/EXTE-
RIOR/COWL GRILLE - REMOVAL).
4. Remove the headlamp unit (Refer to 8 - ELECTRI-
CAL/LAMPS/LIGHTING - EXTERIOR/HEADLAMP
UNIT - REMOVAL).
5. Remove the wheelhouse splash shield (Refer to 23
- BODY/EXTERIOR/FRONT WHEELHOUSE
SPLASH SHIELD - REMOVAL).
6. Remove the bolts (1, 2, 3, 5 and 6) that secure the
front fender (7) to body.
7. Carefully remove the front fender from the body
and remove the plastic inserts (4), if required.
INSTALLATION
1. If required, install new plastic inserts (4) into the
front fender (7).
2. Position the front fender onto the body and loosely
install all fender retaining bolts.
3. Align the front fender and add shims, if required
(Refer to 23 - BODY/BODY STRUCTURE/GAP
AND FLUSH - SPECIFICATIONS).
4. Tighten the bolts (2 and 6) to 9 Nꞏm (80 in. lbs.).
5. Tighten the bolts (1, 3 and 5) to 12.5 Nꞏm (9 ft.
lbs.).
6. Install the wheelhouse splash shield (Refer to 23 -
BODY/EXTERIOR/FRONT WHEELHOUSE
SPLASH SHIELD - INSTALLATION).
7. Install the headlamp unit (Refer to 8 - ELECTRI-
CAL/LAMPS/LIGHTING - EXTERIOR/HEADLAMP
UNIT - INSTALLATION).
8. Install the cowl grille (Refer to 23 - BODY/EXTERI-
OR/COWL GRILLE - INSTALLATION).
9. Install the battery tray, if required (Refer to 8 - ELECTRICAL/BATTERY SYSTEM/TRAY - INSTALLATION).
10. Install the antenna (Refer to 8 - ELECTRICAL/AUDIO/ANTENNA BODY & CABLE - INSTALLATION).

NOTE:
All measurements are in mm. O/F = Over Flush. U/F = Under Flush.
DIMENSION DESCRIPTION GAP FLUSH
7 Quarter to front door 5.0 ± 1.5
Parallel within 1.00.0 ± 1.5
8 Front door to quarter character line
alignment— Up/Down 0.0 ± 1.5
*9 Front door to fender character line
alignment— Up/Down 0.0 ± 1.5
*10 Front door to fender 5.0 ± 1.5
Parallel within 1.00.0 ± 1.5
*11 Bumper to fender 19.0 ± 3.0
Parallel within 3.0O/F 5.0 ± 5.0 (SLT)
O/F 14.0 ± 5.0 (SPORT)
*12 Bumper to headlamp 19.0 ± 4.0 —
*ALLMODELS
NOTE:
All measurements are in mm. O/F = Over Flush. U/F = Under Flush.
DIMENSION DESCRIPTION GAP FLUSH
1 Roof to rear door — U/F 6.0 ± 1.5
Parallel within 1.5
2 Quarter to rear door 5.0 ± 1.5
Parallel within 2.00.0 ± 1.5
3 Rear door to quarter character line
alignment— Up/Down 0.0 ± 1.5
4 Rear door to front door character line
alignment— Up/Down 0.0 ± 1.5
5 Rear door to front door 5.0 ± 1.5
Parallel within 2.00.0 ± 1.5
Fig. 2 GAP & FLUSH - QUAD CAB

NOTE:
All measurements are in mm. O/F = Over Flush. U/F = Under Flush.
DIMENSION DESCRIPTION GAP FLUSH
2 Hood To Grille 1.5 ± 1.0 U/F 0.5 ± 1.75
3 Fender To Hood 6.0 ± 2.0
Parallel Within 1.0U/F 3.2 ± 1.5
(Under flush from front of
hood to start of hockey
stick area only.)
4 Fender To Hood
(Up/Down Surface Only)6.0 ± 2.0
Parallel Within 2.00.0 ± 1.5
5 Front Door To Windshield — O/F 20.5 ± 1.5
(Base of windshield)
O/F 9.0 ± 1.5
(Top of windshield)
6 Front Door To Roof — O/F 6.0 ± 1.5
Parallel within 1.5
7 Rear Door To Roof — O/F 0.0 ± 1.5
8 Rear Door To Quarter Panel 5.0 ± 1.5
Parallel Within 1.50.0 ± 1.5
9 Fuel Door To Outer Box 5.0 ± 1.5
Parallel Within 1.50.0 ± 1.5
10 Rear Door To Quarter Character Line
Alignment— Up/Down 0.0 ± 1.5
11 Rear Door To Front Door 5.0 ± 1.5
Parallel Within 1.50.0 ± 1.5
12 Rear Door To Front Door Character
Line Alignment— Up/Down 0.0 ± 1.5
13 Front Door To Fender 5.0 ± 1.5
Parallel Within 1.5U/F 0.5 ± 1.5
14 Front Door To Fender Character Line
Alignment— Up/Down 0.0 ± 1.5
15 Bumper To Fender 16.0 ± 4.0
Side To Side 3.0O/F 6.5 ± 5.0 (SLT)
O/F 14.5 ± 5.0 (SPORT)
16 Bumper To Headlamp 16.0 ± 4.0 —
17 Tailgate To Outer Box Character Line
Alignment— 0.0 ± 1.5
18 Cab Back To Box Front 31.0 ± 5.0
Parallel Within 1.5—
19 Cab To Box Side 30.5 ± 5.0
Parallel Within 3.0O/F 5.25 ± 3.5
20 Cab To Box Character Line Alignment — Up/Down 0.0 ± 3.0
21 Tailgate To Outer Box 5.0 ± 2.0
Parallel Within 1.5U/F 1.5 ± 1.5
Side to side within 2.0
22 Bumper To Outer Box 24.0 ± 5.0 (F/A)
25.0 ± 5.0 (C/C)
Parallel Within 5.0—
23 Tailgate To Outer Box Character Line
Alignment— Up/Down 0.0 ± 1.5
24 Bumper To Tailgate 30.0 ± 3.0
Parallel Within 4.0—

WELD LOCATIONS
SPECIFICATIONS
INDEX
DESCRIPTION FIGURE
FENDER BRACE, CLOSURE TUBE AND FRAME MOUNTING BRACKET TO FRONT
FENDER SUPPORT, FRONT FENDER AND RADIATOR TUBE46
STEERING COLUMN SUPPORT, CONNECTOR WIRING BRACKET AND WELD NUTS
TO LOWER PLENUM PANEL47
WIPER ATTACHING WELD NUTS AND VACUUM RESERVOIR ATTACHING STUDS TO
COWL PAR PANEL48
DASH PANEL TO FRONT FLOOR PAN 49
DASH PANEL TO LOWER PLENUM PANEL 50
LOWER PLENUM PANEL TO COWL BACK PANEL 51
FRONT FENDER AND RADIATOR TUBE DASH PANEL, INSTRUMENT PANEL
MOUNTING BRACKET, AND WELD NUTS TO COWL SIDE PANEL - LEFT SIDE52
DASH PANEL, LOWER PLENUM PANEL AND COWL PANEL BAR TO COWL SIDE
PA N E L - L E F T S I D E53
FRONT FENDER AND RADIATOR TUBE DASH PANEL, INSTRUMENT PANEL
MOUNTING BRACKET AND WELD NUTS TO COWL SIDE PANEL - RIGHT SIDE54
DASH PANEL, LOWER PLENUM PANEL AND COWL PANEL BAR TO COWL SIDE
PANEL - RIGHT SIDE55
REINFORCEMENT AND HEADLAMP MOUNTING PANEL TO OUTER FENDER PANEL 56
SEAT MOUNTING FRONT BRACKETS TO SEAT MOUNTING FRONT CROSSMEMBER
TO FRONT FLOOR PAN57
AIR BAG MODULE BRACKET SHIFTER MOUNTING PLATE AND REAR FLOOR PANEL
TO FRONT FLOOR PAN58
RIGHT TO LEFT REAR FLOOR CROSSMEMBER AND RIGHT TO LEFT SEAT
MOUNTING CROSSMEMBER59
REAR FLOOR CROSSMEMBER, SEAT MOUNTING CROSSMEMBER AND
UNDERBODY SUPPORT TO FLOOR SILL60
SEAT MOUNTING FRONT CROSSMEMBER TO FRONT FLOOR PAN TO UNDERBODY
SUPPORT61
FRONT SEAT MOUNTING CROSSMEMBERS TO FRONT SEAT MOUNTING BRACKET
TO FRONT FLOOR PAN62
REAR FLOOR CROSSMEMBERS TO REAR FLOOR PAN 63
FLOOR SILL TO FRONT SEAT MOUNTING CROSSMEMBER, FRONT AND REAR
FLOOR PAN64
AIR BAG MODULE BRACKET, SHIFTER MOUNTING PLATE AND FRONT SEAT
MOUNTING CROSSMEMBER TO FRONT FLOOR PAN65
REAR SEAT MIDDLE MOUNTING PLATE TO REAR FLOOR PAN TO FRONT FLOOR
PA N66
REAR FLOOR CROSSMEMBER, SEAT MOUNTING CROSSMEMBER AND
UNDERBODY SUPPORT TO FLOOR SILL67
LEFT REAR CROSSMEMBER TO RIGHT REAR CROSSMEMBER TO REAR FLOOR
PA N68
STORAGE BIN TO RIGHT AND LEFT REAR FLOOR CROSSMEMBER TO REAR
FLOOR PAN69

Fig. 56 HEADLAMP MOUNTING PANEL
