Page 2505 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 13. Check for leaks at all hose connections. SPECIFICATIONS TORQUE DESCRIPTION Nꞏm Ft. Lbs. In. Lbs. Power Steering Line nuts 28 21 — Power Steering Pump Mounting Bolts23 17 200

Page 2506 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SPECIAL TOOLS POWER STEERING ANALYZER SET, POWER STEERING FLOW/ PRESSURE 6815 ADAPTERS, POWER STEERING FLOW/PRESSURE TESTER - 6893 HOSE, POWER STEERING-6959 Transmission Cooler Line Disconnect Tool -

Page 2507 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual HOSES REMOVAL PRESSURE HOSE - PUMP TO FAN NOTE: Review all Warnings and Cautions. (Refer to 19 - STEERING - WARNING). CAUTION: Cap all open ends of power steering hoses, power steering pump fittings a

Page 2508 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2. Unthread power steering pressure hose quick-con- nect (6) from hydraulic fan (1). Drain excess power steering fluid from line. 3. Unthread power steering pressure hose tube nut from power steering

Page 2509 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CAUTION: Cap all open ends of power steering hoses, power steering pump fittings and steering gear ports when disconnected. This will prevent the entry of foreign material into the components during s

Page 2510 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual RETURN HOSE - COOLER TO PUMP NOTE: Review all Warnings and Cautions. (Refer to 19 - STEERING - WARNING). CAUTION: Cap all open ends of power steering hoses, power steering pump fittings and steering g

Page 2511 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. If pressure hose is separate from quick-connect fittings: a. Thread quick-connect fitting into power steering pump pressure fitting (10). Tighten hose fitting to 28 Nꞏm (21 ft. lbs.) torque. b. S

Page 2512 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual RETURN HOSE - FAN TO PUMP NOTE: Before installing power steering hose, clean open power steering hose ends and fittings with a lint- free towel. 1. Slide hose clamps onto ends of return hose far enoug
