DODGE RAM SRT-10 2006 Service Repair Manual 18. Remove fifth gear (1) and bearing from counter- shaft (2). 19. Remove 5-6 gear (1) from mainshaft with Puller 9379 (2), Bolts 9378 and Bridge 9382. 20. Remove shift fork (1) and 5-6 synchronizer s

Page 2674 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 21. Remove 5-6 synchronizer snap ring and synchro- nizer hub (1) from countershaft (2). 22. Remove sixth gear synchronizer stop ring (1) from countershaft (2). 23. Remove sixth gear (1), bearing and t

Page 2675 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 24. Remove top cover plate (2) bolts and pry off cover. 25. Remove shift detent (1) assembly. 26. Drive roll pin down with punch (1) into front offset lever (3) until loose. 27. Remove reverse lockout

Page 2676 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 29. Remove two torx screws (2) located on the top of the transmission case (1). 30. Remove clutch slave cylinder from transmission. 31. Remove all front adapter plate (2) bolts (3) except one to hold

Page 2677 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 34. Remove remaining adapter bolt and pry transmis- sion case (1) upward. Remove offset lever from shift rail and case from adapter plate (2). 35. Remove reverse rail (2) assembly.

Page 2678 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 36. Tilt countershaft (4) sideways and lift mainshaft (1) and shift rail a (2) assemblies out of adapter plate (3). 37. Remove countershaft (1) assembly.

Page 2679 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 38. Remove input shaft (2) from adapter (3). MAINSHAFT NOTE: Mainshaft snap rings are not interchange- able. 1. Remove and discard mainshaft (2) O-ring (3). 2. Remove rear mainshaft (2) bearing (1).

Page 2680 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Remove first gear (1) and bearing (2) from mainshaft. 4. Remove 1-2 synchronizer (1) snap ring (2) from mainshaft. 5. Remove 1-2 thrust washer (1) and blocker ring assembly from mainshaft.
