DODGE RAM SRT-10 2006  Service Repair Manual INSTALLATION
CAUTION: The longer push rods are for the
exhaust side, and the shorter push rods are for
intake side.
1. Install the push rods in the same order as
removed.
2. Install the pushrod retain

Page 1810 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual CAUTION: The rocker shaft assemblies are not
interchangeable between intake and exhaust. The
intake rocker arms are marked with the letter “I”.
3. Install rocker shaft assemblies in the same order

Page 1811 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 6. Install cylinder head cover (Refer to 9 - ENGINE/
CYLINDER HEAD/CYLINDER HEAD COVER(S) -
INSTALLATION).

Page 1812 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual SEALS - VALVE GUIDE
DESCRIPTION
The valve guide seals are made of rubber and incorporate an integral steel valve spring seat. The integral garter
spring maintains consistent lubrication control to the

Page 1813 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual SPRINGS - VALVE
REMOVAL
1. Disconnect negative battery cable.
2. Remove air cleaner assembly.
3. Remove air intake resonator.
4. Remove ignition coil connector (1).
5. Remove ignition coils (2).
6. Re

Page 1814 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual

Page 1815 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 7. Remove cylinder head cover (1) using the
sequence shown (Refer to 9 - ENGINE/CYLINDER
HEAD/CYLINDER HEAD COVER(S) - REMOVAL).
CAUTION: The piston must be at TDC, and both
valves closed on the cylin

Page 1816 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 8. Remove exhaust/intake rocker arm shafts using the
sequence shown.
9. Install rocker arm shaft (1) special tool# 9065.
