2006 DODGE RAM SRT-10 Service Repair Manual

Page 3025 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 14. Remove the number 2 needle bearing (1).
15. Remove the OD/UD reaction plate tapered snap
ring (1).
NOTE: The OD/UD clutch reaction plate has a step
on both sides. The OD/UD clutches reaction plate

Page 3026 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 17. Remove the first UD clutch disc (1).
18. Remove the UD clutch flat snap ring (1).
NOTE: Tag underdrive clutch pack for reassembly
identification.
19. Remove the UD clutch pack (1, 3).

Page 3027 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual CAUTION: Compress return spring just enough to
remove or install snap ring.
20. Using Compressor 5059A (4) and an arbor press
(2), compress UD clutchpiston enough to remove
snap ring (3).
21. Remove t

Page 3028 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 23. Remove the input hub tapered snap ring (2).
24. Tap on input hub (1) with soft faced hammer (2)
and separate input hub from OD/Reverse piston
and clutch retainer.
25. Separate the input hub from O

Page 3029 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 26. Separate clutch retainer (2) from OD/Reverse pis-
ton (1).
27. Using Disc 6057 (4) and an arbor press (1), com-
press OD/Reverse piston (5) return spring just
enough to remove snap ring (3).
28. R

Page 3030 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 29. Remove input shaft (1) to input clutch hub snap
ring (3).
30. Using a suitably sized socket (2) and an arbor
press (1), remove input shaft (5) from input shaft
hub.
ASSEMBLY
Use petrolatum on all

Page 3031 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 2. Install input shaft snap ring (3).
3.PositiontheOD/Reversepistonreturnspring(2)
and snap ring (3) onto the OD/Reverse piston (1).
4. Using an arbor press (1) and Disc 6057 (4), install
theOD/Revers

Page 3032 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 5. Install the OD/Reverse piston (1) assembly to the
input clutch retainer (2).
6. Install the input hub/shaft assembly (1) to the
OD/Reverse piston/clutch retainer assembly (2).
7. Install input hub
