Page 3897 of 5267
BEARING-OUTPUT SHAFT REAR
REMOVAL
1. Remove overdrive unit from the vehicle. (Refer to
21 - TRANSMISSION/AUTOMATIC/OVERDRIVE -
REMOVAL)
2. Remove overdrive geartrain from housing.
3. Remove snap-ring (3) holding output shaft rear
bearing (1) into overdrive housing (2).
4. Using a suitable driver inserted through the rear
end of housing, drive bearing from housing.
INSTALLATION
1. Place replacement bearing (1) in position in hous-
ing (2).
2. Using a suitable driver, drive bearing (1) into hous-
ing (2) until the snap-ring groove is visible.
3. Install snap-ring (3) to hold bearing into housing.
4. Install overdrive geartrain into housing.
5. Install overdrive unit in vehicle.
Page 3898 of 5267

CLUTCH-OVERDRIVE
DESCRIPTION
The overdrive clutch is composed of the pressure plate (2), clutch plates,holding discs, overdrive piston retainer,
piston, piston spacer, and snap-rings. The overdrive clutch is the forwardmost component in the transmission over-
drive unit and is considered a holding component. The overdrive piston retainer, piston, and piston spacer are
located on the rear of the main transmission case.
NOTE: The number of discs and plates may vary with each engine and vehicle combination.
OPERATION
To apply the clutch, pressure is applied between the piston retainer and piston. The fluid pressure is provided by the
oil pump, transferred through the control valves and passageways, and enters the clutch through passages at the
lower rear portion of the valve body area. With pressure applied between the piston retainer and piston, the piston
moves away from the piston retainer and compresses the clutch pack. This action applies the clutch pack, allowing
torque to flow through the intermediate shaft into the overdrive planetary gear set. The overdrive clutch discs are
attached to the overdrive clutch hub while the overdrive clutch plates, reaction plate, and pressure plate are lugged
to the overdrive housing. This allows the intermediate shaft to transfer the engine torque to the planetary gear and
overrunning clutch. This drives the planetary gear inside the annulus, which is attached to the overdrive clutch drum
and output shaft, creating the desired gear ratio. The waved snap-ring is used to cushion the application of the
clutch pack for the 5 disc version of the overdrive clutch. The 6 disc overdrive clutch does not use a waved snap-
ring.
Overdrive Clutch
1 - REACTION PLATE 2 - PRESSURE PLATE
Page 3899 of 5267

UNIT-OVERDRIVE
REMOVAL
1. Shift transmission into PARK.
2. Raise vehicle.
3. Remove transfer case, if equipped.
4. Mark propeller shaft universal joint(s) and axle pinion yoke, or the companion flange and flange yoke, for align-
ment reference at installation, if necessary.
5. Disconnect and remove the rear propeller shaft, if necessary. (Refer to3 - DIFFERENTIAL & DRIVELINE/PRO-
PELLER SHAFT/PROPELLER SHAFT - REMOVAL)
6. Remove transmission oil pan, remove gasket, drain oil and reinstall pan.
7. If overdrive unit had malfunctioned, or if fluid is contaminated, remove entire transmission. If diagnosis indicated
overdrive problems only, remove just the overdrive unit.
8. Support transmission with transmission jack.
9. Remove bolts (2) attaching overdrive unit (1) to
transmission.
CAUTION: Support the overdrive unit with a jack
before moving it rearward. This is necessary to
prevent damaging the intermediate shaft. Do not
allow the shaft to support the entire weight of the
overdrive unit.
10. Carefully work overdrive unit off intermediate
shaft. Do not tilt unit during removal. Keep it as
level as possible.
11. If overdrive unit does not require service, immedi-
ately insert Alignment Tool 6227-2 in splines of
planetary gear and overrunning clutch to prevent
splines from rotating out of alignment. If misalign-
ment occurs, overdrive unit will have to be disas-
sembled in order to realign splines.
12. Remove and retain overdrive piston thrust bearing. Bearing may remainon piston or in clutch hub during
removal.
13. Position drain pan on workbench.
14. Place overdrive unit over drain pan. Tilt unit to drain residual fluid from case.
15. Examine fluid for clutch material or metal fragments. If fluid contains these items, overhaul will be necessary.
16. If overdrive unit does not require any service, leave alignment tool inposition. Tool will prevent accidental mis-
alignment of planetary gear and overrunning clutch splines.
Page 3900 of 5267
DISASSEMBLY
1. Remove transmission speed sensor (2) and o-ring
seal (3) from overdrive case.
2. Remove overdrive piston thrust bearing (1).
Page 3901 of 5267
OVERDRIVE PISTON
1. Remove overdrive piston thrust plate (2). Retain
thrust plate. It is a select fit part and may possibly
be reused.
2. Remove intermediate shaft spacer (2). Retain
spacer. It is a select fit part and may possibly be
reused.
3. Remove overdrive piston (2) from retainer (1).
Page 3902 of 5267
OVERDRIVE CLUTCH PACK
1. Remove overdrive clutch pack wire retaining ring
(1).
2. Remove overdrive clutch pack (1).
3. Note position of clutch pack components for
assembly reference (1-4).
Page 3903 of 5267
OVERDRIVE GEARTRAIN
1. Remove overdrive clutch wave spring (1), 5 disc
clutch only.
2. Remove overdrive clutch reaction snap-ring (1).
Note that snap-ring is located in same groove as
wave spring.
3. Remove Torx™ head screws (1) attach access
cover and gasket to overdrive case.
4. Remove access cover and gasket (1).
Page 3904 of 5267
5. Expand output shaft bearing snap-ring (1) with
expanding-type snap-ring pliers. Then push output
shaft forward to release shaft bearing from locating
ring.
6. Lift gear case (2) up and off geartrain assembly (1).
7. Remove snap-ring (3) that retains rear bearing (2)
on output shaft (1).
8. Remove rear bearing from output shaft.
DIRECT CLUTCH, HUB AND SPRING
WARNING: The next step in disassembly involves compressing the direct clutch spring. It is extremely
important that proper equipment be used to compress the spring as spring forceisapproximately830
pounds. Use spring compressor tool 6227-1 and a hydraulic shop press with aminimum ram travel of 5-6
inches. The press must also have a bed that can be adjusted up or down as required. Release clutch spring
tension slowly and completely to avoid personal injury.
