Page 489 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.INLET AIR PRESSURE SENSOR While monitoring scan tool, use a jumper wire to connect the (K668) 5-volt supply circuit with the (K616) signal circuit at the sensor harness connector. Does the scan tool

Page 490 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6.(K616) SIGNAL CIRCUIT OPEN Measure the resistance between the (K616) signal circuit in the Inlet Air Pressure sensor harness connector and the (K616) signal circuit in the ECM harness connector. Is

Page 491 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8.(K616) SIGNAL CIRCUIT SHORTED TO GROUND Measure the resistance between the (K616) signal circuit in the inlet Air Pressure sensor connector and battery negative. Is the resistance greater than 100 K

Page 492 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0108-INLET AIR PRESSURE SENSOR VOLTAGE TOO HIGH For a complete wiring diagramRefer to Section 8W.

Page 493 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With the ignition on and battery voltage greater than 10.4 volts. Set Condition: The circuit voltage to the ECM is above a calibrated threshold for a certainperiod of time. Possible Ca

Page 494 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.INLET AIR PRESSURE SENSOR While monitoring scan tool, use a jumper wire to connect the (K690) Return circuit to the (K616) signal circuit at the Inlet Air Pressure sensor harness connector. Does the

Page 495 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6.SIGNAL CIRCUIT SORTED TO (K668) 5-VOLT SUPPLY Turn the ignition off. Measure the resistance between the (K616) signal circuit and the (K668) 5-volt supply circuit of the Inlet Air Pressure sensor ha

Page 496 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8.ECM Install the ECM harness connector. Turn the ignition on. While monitoring scan tool, use a jumper wire to connect the (K916) Return circuit with the (K616) signal circuit at the Inlet Air Pressu
