DODGE RAM SRT-10 2006 Service Repair Manual 2. Remove front planetary gear (3) and front annulus gear (2) as assembly. 3. Remove front planetary gear (1) and thrust washer (2) from front annulus gear (3). Note thrust washer position for assembl

Page 3930 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Remove sun gear (3) and driving shell (2) as assembly. 6. Remove tabbed thrust washer (2) from rear plane- tary sun gear (1). Note washer position on gear for assembly reference. 7. Remove rear pla

Page 3931 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 8. Remove thrust washer (2) from rear planetary annulus gear (1). INSPECTION Inspect the planetary gear sets and annulus gears. The planetary pinions,shafts, washers, and retaining pins are serviceabl

Page 3932 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Install rear annulus gear (1) on intermediate shaft (2). 4. Install thrust washer (2) to rear planetary annulus gear (1) using petroleum jelly. Be sure washer is seated against corner witht teh tab

Page 3933 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6. Install tabbed thrust washer (2) on front face of rear planetary gear (1). Seat washer tabs in match- ing slots in face of gear carrier. Use extra petro- leum jelly to hold washer in place if desir

Page 3934 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 10. Install tabbed thrust washer (1) on front planetary gear (2). Seat washer tabs in matching slots in face of gear carrier. Use extra petroleum jelly to hold washer in place if desired. 11. Install

Page 3935 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 13. Install front planetary and annulus gear assembly (2). Hold gears together and slide them onto shaft. Be sure planetary pinions are seated on sun gear and that planetary carrier is seated on inter

Page 3936 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 16. Turn planetary geartrain over. Position wood block under front end of intermediate shaft and support geartrain on shaft. Be sure all geartrain parts have moved forward against planetary snap-ring.
