2006 DODGE RAM SRT-10 Service Repair Manual

wiper bladeschange languagegearboxcenter consolerun flatdiagnostic menu
Popular search:
headrestsport modespare tire locationrear entertainmentcoolingCrank pulley boltoverheating
Previous
Next
Load previous 8 pages

Page 1657 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CAUTION: Do not lay the cylinder head on its gasket sealing surface, due to the design of the cylinder head gasket any distortion to the cylinder head sealing surface may prevent thegasket from proper

Page 1658 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 12. Verify the V8 mark on the camshaft sprocket is at the 12 o’clock position(2). Rotate the crankshaft one turn if necessary. 13. Remove the crankshaft damper (Refer to 9 - ENGINE/ENGINE BLOCK/VIBR

Page 1659 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 18. Remove the cylinder head access plug (1). 19. Remove the right side secondary chain guide (Refer to 9 - ENGINE/VALVE TIMING/TIMING BELT/CHAIN AND SPROCKETS - REMOVAL). 20. Remove the retaining bol

Page 1660 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION INSTALLATION - LEFT CYLINDER HEAD NOTE: The cylinder head bolts are tightened using a torque plus angle procedure. The bolts must be examined BEFORE reuse. If the threads are necked down

Page 1661 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Lubricate the cylinder head bolt threads with clean engine oil and install the ten M11 bolts. 5. Coat the four M8 cylinder head bolts withMopar Lock and Seal Adhesivethen install the bolts. NOTE: T

Page 1662 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 12. Remove Special Tool 8515 (6). 13. Install the timing chain cover (Refer to 9 - ENGINE/VALVE TIMING/TIMING BELT / CHAIN COVER(S) - INSTALLATION). 14. Install the crankshaft damper (Refer to 9 - ENG

Page 1663 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CAUTION: When cleaning cylinder head and cylin- der block surfaces, DO NOT use a metal scraper because the surfaces could be cut or ground. Use only a wooden or plastic scraper (1). 1. Clean the cylin

Page 1664 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 7. Position the secondary chain onto the camshaft drive gear, making sure one marked chain link is on either side of the V8 mark on the gear (2) and position the gear onto the camshaft. 8. Install the
