Page 4561 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Before proceeding with the following repair proce- dure, review all warnings and cautions. (Refer to 23 - BODY/SEATS - WARNING) NOTE: Do not reuse the seat fasteners, always replace wi

Page 4562 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CENTER ARMREST / SEAT BACK REMOVAL 1. Before proceeding with the following repair proce- dure, review all warnings and cautions. (Refer to 23 - BODY/SEATS - WARNING) NOTE: Do not reuse the seat fasten

Page 4563 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CENTER SEAT BACK INERTIA HINGE COVER REMOVAL NOTE: Free pivot hinge cover is removed with the free pivot hinge (Refer to 23 - BODY/SEATS/CEN- TER SEAT BACK HINGE - REMOVAL). 1. For the inertia hinge c

Page 4564 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION NOTE: Free pivot hinge cover is installed with the free pivot hinge (Refer to 23 - BODY/SEATS/CEN- TER SEAT BACK HINGE - INSTALLATION). 1. Position the hinge cover (1) over the hinge (2)

Page 4565 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual CENTER SEAT BACK HINGE REMOVAL FREE PIVOT/HINGE COVER NOTE: Do not reuse the seat fasteners, always replace with new ones. 1. Remove the seat back (Refer to 23 - BODY/ SEATS/CENTER ARMREST/SEAT BACK -

Page 4566 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Open the hinge cover flap (1) and remove the wire harness (5 - if equipped). 6. Remove the cover (3) from the hinge (4). INERTIA HINGE NOTE: Do not reuse the seat fasteners, always replace with new

Page 4567 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION FREE PIVOT HINGE/COVER NOTE: Do not reuse the seat fasteners, always replace with new ones. 1. Position the pivot hinge cover (3) over the pivot hinge (4) and install the 12v power supply

Page 4568 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Install a new pivot bolt (1) and tighten to 25 Nꞏm (18 ft. lbs.). 5. Install the center seat back (Refer to 23 - BODY/ SEATS/CENTER ARMREST/SEAT BACK - INSTALLATION). INERTIA HINGE NOTE: Do not r
