Page 825 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P2123-PPS 1 VOLTAGE TOO HIGH For a complete wiring diagramRefer to Section 8W.

Page 826 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: While the key is on and during engine operation. Set Condition: The APPS signal circuit voltage at the ECM goes above 4.24 volts for more than 2 seconds. Possible Causes (K167) APPS NO

Page 827 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2.(K23) APPS NO. 1 SIGNAL CIRCUIT SHORTED TO (K852) APPS NO. 1 5-VOLT SUPPLY Measure the resistance between the (K23) APPS No. 1 signal circuit in the sensor harness connector and the (K852) APPS No.

Page 828 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4.ECM Reconnect the ECM harness connectors. Reconnect the APPS harness connector. While monitoring with the scan tool, disconnect the sensor connector. Did a APPS No. 1 and APPS No. 2 voltage too low

Page 829 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P2127-PPS 2 VOLTAGE TOO LOW For a complete wiring diagramRefer to Section 8W.

Page 830 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: While the key is on and during engine operation. Set Condition: The APPS circuit voltage at the ECM goes below 0.13 volt for more than 2 seconds. Possible Causes APPS ECM (K29) APPS NO

Page 831 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 2.(F856) APPS NO. 2 5-VOLT SUPPLY OPEN Measure the resistance of the (F856) APPS No. 2 5-volt supply circuit between the APPS sensor harness connector and the ECM harness connector. Is the resistance

Page 832 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4.(K29) APPS NO. 2 SIGNAL CIRCUIT SHORTED TO OTHER CIRCUITS Measure the resistance between the (K29) APPS No. 2 signal circuit at the ECM harness connector and all other circuits in the ECM harness co
