SUPPORT CYLINDER
REMOVAL
NOTE: The hood support cylinders can be
replaced one at a time.
1. Open and support the hood.
CAUTION: Do not pull on the hood support cylin-
ders at the middle of the support cylinder during
removal. Failure to followthis caution can result in
damage to the hood support cylinders.
2. Using a small flat bladed tool, or equivalent (3),
release the retaining clip (2) at each end of the
support cylinder while carefully pulling the ball
socket (1) away from the ball stud (4).
NOTE: Lift the clips (1) only enough to release the
ball studs (3).
Page 4474 of 5267
3. Disconnect the hood support cylinder (5) from the
hood (1) and the fender rail (3).
4. If required, remove the upper ball stud (2) from
hood and the lower ball stud (4) from the fender
rail.
INSTALLATION
1. If removed, install the upper ball stud (2) onto the
hood (1) and the lower ball stud (4) onto the fender
rail (3). Install the ball studs securely.
CAUTION: Do not push on the hood support cylin-
ders at the middle of the support cylinder during
installation. Failure to follow this caution can
result in damage to the hood support cylinders.
NOTE: Install the hood support cylinders with the
cylinder end connected to the hood as shown.
NOTE: If required, only release each retaining clip
enough to install the ball socket onto the ball
stud.
2. Install the hood support cylinder (5) over the upper
and lower ball studs and fully engage the retaining
clips.
Page 4475 of 5267

page page
CLUSTER BEZEL
REMOVAL ................................... 139
INSTALLATION .............................. 140
CUP HOLDER
REMOVAL ................................... 141
INSTALLATION .............................. 142
GLOVE BOX
REMOVAL ................................... 144
INSTALLATION .............................. 144
GLOVE BOX LATCH
REMOVAL ................................... 145
INSTALLATION .............................. 146
INSTRUMENT PANEL ASSEMBLY
REMOVAL ................................... 147
INSTALLATION .............................. 155
INSTRUMENT PANEL CENTER BEZEL
REMOVAL ................................... 164
INSTALLATION .............................. 165
INSTRUMENT PANEL DRIVER SIDE BEZEL
REMOVAL ................................... 166INSTALLATION .............................. 166
INSTRUMENT PANEL LOWER SURROUND
REMOVAL ................................... 167
INSTALLATION .............................. 167
INSTRUMENT PANEL TOP COVER
REMOVAL ................................... 169
INSTALLATION .............................. 169
STEERING COLUMN OPENING COVER
REMOVAL ................................... 170
INSTALLATION .............................. 171
STEERING COLUMN OPENING SUPPORT
BRACKET
REMOVAL ................................... 173
INSTALLATION .............................. 174
STORAGE BIN
REMOVAL ................................... 175
INSTALLATION .............................. 175
Page 4476 of 5267

CLUSTER BEZEL
REMOVAL
WARNING: On vehicles equipped with airbags, disable the airbag system before attempting any steering
wheel, steering column, seat belt tensioner, or instrument panel component diagnosis or service. Discon-
nect and isolate the battery negative (ground) cable, then wait two minutes for the airbag system capacitor
to discharge before performing further diagnosis or service. This is the only sure way to disable the airbag
system. Failure to take the proper precautions could result in accidentalairbag deployment and possible
personal injury or death.
1. Disconnect and isolate the negative battery cable.
2. Remove the steering column opening cover. (Refer
to 23 - BODY/INSTRUMENT PANEL/STEERING
COLUMN OPENING COVER - REMOVAL)
3. Remove the screws (2) that secure the top of the instrument cluster bezel(1) to the instrument panel.
4. Using a trim stick C-4755 or equivalent, disengage the two retainer clips that secure the top of the instrument
cluster bezel to the instrument panel.
Page 4477 of 5267
5. Carefully disengage the instrument cluster bezel from the instrument panel opening and remove the bezel.
INSTALLATION
1. Install the instrument cluster bezel onto the instrument panel and fully engage the two retainer clips to the instru-
ment panel.
2. Install the screws (2) that secure the instrument cluster bezel to the instrument panel.
3. Install the steering column opening cover. (Refer to
23 - BODY/INSTRUMENT PANEL/STEERING
COLUMN OPENING COVER - INSTALLATION)
4. Connect the negative battery cable.
Page 4478 of 5267
CUP HOLDER
REMOVAL
1. Remove the bezel (2).
2. Remove the screws (2) and remove the cup holder
(1).
Page 4479 of 5267
INSTALLATION
1. Position the cup holder (2) onto the clips (1) and
seat fully.
2. Install the screws (2).
Page 4480 of 5267
3. Position the bezel and seat the clips fully.
