Page 4385 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual TRIM PANEL REMOVAL 1. Remove the screw (1) that secures the interior door handle (2) to the interior door handle actuator (3). 2. Remove the interior door handle from the interior door handle actuator

Page 4386 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. If equipped, connect the door wire harness to the power door switch assembly. CAUTION: The door trim panel is attached to the door by molded plastic retaining clips that are integral t

Page 4387 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual WATERDAM REMOVAL 1. Remove the interior door handle actuator (Refer to 23 - BODY/DOOR - FRONT/INTERIOR HANDLE ACTUATOR - REMOVAL). 2. Remove the speaker (Refer to 8 - ELECTRICAL/ AUDIO/SPEAKER - REMOV

Page 4388 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual WINDOW REGULATOR - POWER REMOVAL 1. Remove the inner belt molding (Refer to 23 - BODY/WEATHERSTRIP/SEALS/FRONT DOOR INNER BELT WEATHERSTRIP - REMOVAL). 2. Remove the waterdam (Refer to 23 - BODY/DOOR

Page 4389 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Connect the door wire harness (6) to the window regulator (4) and install the regulator through the opening in the door (2). 2. Engage the two regulator bolts (7) to the door. 3. Insta

Page 4390 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual WINDOW REGULATOR - MANUAL REMOVAL 1. Remove the inner belt molding (Refer to 23 - BODY/WEATHERSTRIP/SEALS/FRONT DOOR INNER BELT WEATHERSTRIP - REMOVAL). 2. Remove the waterdam (Refer to 23 - BODY/DOOR

Page 4391 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSTALLATION 1. Install the window regulator (4) through the opening in the door (2). 2. Engage the two regulator bolts (6) to the door. 3. Install the two bolt (5) that secure the window reg- ulator

Page 4392 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual SIDE VIEW MIRROR FLAG REMOVAL 1. Remove the door trim panel (4) (Refer to 23 - BODY/DOOR - FRONT/TRIM PANEL - REMOVAL). CAUTION: Do not use a drill to remove the heat stakes. The remaining portions of
