Page 1945 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3. Starting with the center bolt, torque bolts (1) to 24 Nꞏm ( 18 ft. lbs. ). 4. Install breather tube (3) to cylinder head cover (2). 5. Install breather drain tube (4) to cylinder head cover (2).

Page 1946 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 5. Connect injector harness connectors (3) at cylinder head cover gasket.

Page 1947 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual VALVES & SEATS - INTAKE/EXHAUST DESCRIPTION The valves (1,2) are made of heat resistant steel, and have chrome plated stems to prevent scuffing. The intake and exhaust valves are both similar in head

Page 1948 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Install the compressor top plate, washer, and nut. Using a suitable wrench, tighten the nut (clockwise) to compress the valve springs and remove the locks. 5. Rotate the compressor nut counter-cloc

Page 1949 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual INSPECTION Visually inspect the valves for abnormal wear on the heads, stems, and tips. Replace any valve that is worn out or bent. Measure the valve stem diameter in three places as shown. VALVE GUID

Page 1950 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Measure the cylinder head valve guide bore. Measure valve margin (rim thickness). Measure the valve spring free length and maximum inclination.

Page 1951 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual Test valve spring force with tool C-647 (1). Specifica- tion 72.0 — 80.7 lbs. when compressed to 35.33 mm (1.39 in.). INSTALLATION 1. Install new valve seals. The yellow seals are for the intake val

Page 1952 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4. Install the valve spring compressor tool 8319–A (1)as shown. 5. Compress the valve springs and install the valve retaining locks. 6. Remove the compressor and repeat the procedure on the remainin
