Page 169 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 9.(K22) TP SENSOR NO.1 SIGNAL CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (K22) TP Sensor No.1 Signal circuit in the TP Sensor harness connector. Istheresistancebelow100ohm

Page 170 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 11 .EXCESSIVE RESISTANCE IN THE (F856) 5-VOLT SUPPLY CIRCUIT Turn the ignition off. Disconnect the MAP Sensor harness connector. Disconnect the C1 PCM harness connector. CAUTION: Do not probe the PCM

Page 171 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 13.MAP SENSOR Turn the ignition off. Connect the C1 PCM harness connector. Ignition on, engine not running. With a scan tool, monitor the MAP Sensor voltage. Connect a jumper wire between the (K1) MAP

Page 172 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 15.(K1) MAP SIGNAL CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (K1) MAP Signal cir- cuit in the MAP Sensor harness connector. Istheresistancebelow100ohms? Ye s>> Repair the

Page 173 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 17.PCM NOTE: Before continuing, check the PCM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness an

Page 174 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P2096-DOWNSTREAM FUEL TRIM SYSTEM 1 LEAN For a complete wiring diagramRefer to Section 8W.

Page 175 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With the engine running in closed loop mode, the ambient/battery temperature above (-7°C) 20°F, altitude below 8500 ft. Set Condition: If the PCM multiplies short term compensation b

Page 176 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 3.ENGINE MECHANICAL Check for any of the following conditions/mechanical problems. AIR INDUCTION SYSTEM - must be free from leaks ENGINE VACUUM - must be at least 13 inches in neutral ENGINE VALVE TIM
