Page 4433 of 5267
FUEL FILL DOOR
REMOVAL
1. Open the fuel filler door (1).
2. Remove the two bolts (2) that secure the fuel filler
door to the cargo box and remove the door.
INSTALLATION
1. Position and align the fuel filler door (1) to the
cargo box.
2. Install the two bolts (2) that secure the fuel filler
door to the cargo box. Tighten the bolts to 9 Nꞏm
(80 in. lbs.).
Page 4434 of 5267
GRILLE
REMOVAL
1. Open the hood (2) and remove the six screws (5)
that secure the grille (3) to the grille frame (4).
2. Remove the six nuts (1) that secure the grille to the
hood and remove the grille.
3. If required, remove the grille frame from the hood
(Refer to 23 - BODY/EXTERIOR/GRILLE FRAME -
REMOVAL).
INSTALLATION
1. If removed, install the grille frame (4) (Refer to 23 -
BODY/EXTERIOR/GRILLE FRAME - INSTALLA-
TION).
2. Position and align the grille (3) onto the hood (2)
3. Install the six nuts (1) that secure the grille to the
hood. Tighten the nuts to 5 Nꞏm (44 in. lbs.).
4. Install the six screws (5) that secure the grille to
the grille frame. Tighten the screws to 2.2 Nꞏm (20
in. lbs.).
Page 4435 of 5267
GRILLE FRAME
REMOVAL
1. Remove the grille (Refer to 23 - BODY/EXTERIOR/
GRILLE - REMOVAL).
2. Remove the six screws (3) that secure the grille
frame (2) to the hood (1) and remove the frame.
INSTALLATION
1. Position the grille frame (2) onto the hood (1).
2. Install the six screws (3) that secure the grille
frame to the hood. Tighten the screws to 5 Nꞏm (44
in. lbs.).
3. Install the grille (Refer to 23 - BODY/EXTERIOR/
GRILLE - INSTALLATION).
Page 4436 of 5267
REAR FENDER-QUAD CAB MODELS
REMOVAL
1. Disconnect and isolate the negative battery cable.
2. Remove the tail lamp unit (Refer to 8 - ELECTRI-
CAL/LAMPS/LIGHTING - EXTERIOR/TAIL LAMP
UNIT - REMOVAL).
3. Remove the rear wheelhouse splash shield (Refer
to 23 - BODY/EXTERIOR/REAR WHEELHOUSE
SPLASH SHIELD - REMOVAL).
4. Remove the two marker lamp units from the rear
fender (Refer to 8 - ELECTRICAL/LAMPS/LIGHT-
ING - EXTERIOR/MARKER LAMP UNIT -
REMOVAL).
5. Remove the two nuts (2) that secure the rear
fender to the cargo box near the tail lamp opening
(1).
6. Raise and support the vehicle.
7. Remove the two nuts (1) that secure the rear
fender to the rear of the cargo box inner panel (2).
8. Remove the four bolts that secure the bottom
edges of the rear fender to the cargo box.
Page 4437 of 5267
9. Remove the four nuts (2) secure the front of the
rear fender to the cargo box inner panel (1)
10. Loosen the three bolts (3) on each of the two
fender support brackets (1) located on the cargo
box outer panel (2).
CAUTION: Prior to removing the rear fenders,
mask off the surrounding cargo box areas to avoid
damage to the cargo box painted surfaces.
11. Lift the rear fender straight up and off of the two
support brackets and remove the fender.
INSTALLATION
CAUTION: Prior to installing the rear fenders,
mask off the surrounding areas to avoid damage
to the cargo box painted surfaces.
1. Carefully position the rear fender onto the three
bolts (3) on each of the two support brackets (1)
located on the cargo box outer panel (2).
Page 4438 of 5267
2. Install the four nuts (2) that secure the front of the
rear fender to the cargo box inner panel (1).
Tightenthenutsto7Nꞏm(60in.lbs.).
3. Install the two nuts (1) that secure the rear fender
to the rear of the cargo box inner panel (2). Tighten
thenutsto7Nꞏm(60in.lbs.).
4. Install the four bolts that secure the bottom edges
of the rear fender to the cargo box. Tighten the
bolts to 7 Nꞏm (60 in. lbs.).
5. Tighten the three bolts on each of the two support
brackets to 11 Nꞏm (8 ft. lbs.).
Page 4439 of 5267
6. Lower the vehicle.
7. Install the two nuts (2) that secure the rear fender
to the cargo box near the tail lamp opening (1).
Tightenthenutsto7Nꞏm(60in.lbs.).
8. Install the two marker lamp units onto the rear
fender (Refer to 8 - ELECTRICAL/LAMPS/LIGHT-
ING - EXTERIOR/MARKER LAMP UNIT - INSTAL-
LATION).
9. Install the rear wheelhouse splash shield (Refer to
23 - BODY/EXTERIOR/REAR WHEELHOUSE
SPLASH SHIELD - INSTALLATION).
10. Install the tail lamp unit (Refer to 8 - ELECTRI-
CAL/LAMPS/LIGHTING - EXTERIOR/TAIL LAMP
UNIT - INSTALLATION).
11. Reconnect the negative battery cable.
Page 4440 of 5267
SIDE VIEW MIRROR
REMOVAL
1. Remove the door trim panel (Refer to 23 - BODY/
DOOR - FRONT/TRIM PANEL - REMOVAL).
2. Disconnect the wire harness connector (3) from the
mirror (1).
3. Remove the three nuts (2) that secure the mirror to
the door and carefully remove the mirror.
INSTALLATION
1. Position the mirror (1) onto the door.
2. Install the three nuts (2) that secure the mirror to
the door. Tighten the nuts to 7 Nꞏm (60 in. lbs.).
3. Connect the wire harness connector (3) to the mir-
ror.
4. Install the door trim panel (Refer to 23 - BODY/
DOOR - FRONT/TRIM PANEL - INSTALLATION).
