DODGE RAM SRT-10 2006 Service Repair Manual P0522-OIL PRESSURE CIRCUIT LOW For a complete wiring diagramRefer to Section 8W.

Page 1306 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: Ignition on. Set Condition: When the PCM recognizes the Oil Pressure signal voltage lower than 0.3 of a volt. Possible Causes (F855) 5-VOLT SUPPLY CIRCUIT OPEN (F855) 5-VOLT SUPPLY CIR

Page 1307 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4.(G6) OIL PRESSURE SIGNAL CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the C2 PCM harness connector. Measure the resistance between (G6) Oil Pressure Signal circuit and ground at the S

Page 1308 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 6.(F855) 5-VOLT SUPPLY CIRCUIT OPEN Turn the ignition off. Disconnect the C1 PCM harness connector. Measure the resistance of the (F855) 5-volt Supply circuit from the Sen- sor harness connector to th

Page 1309 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0523-OIL PRESSURE CIRCUIT HIGH For a complete wiring diagramRefer to Section 8W.

Page 1310 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual When Monitored: With the ignition on and battery voltage above 10.4 volts. Set Condition: The oil pressure sensor signal at PCM goes above 4.9 volts. One Trip Fault. Possible Causes OIL PRESSURE SENSO

Page 1311 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual 4.(G6) OIL PRESSURE SIGNAL CIRCUIT OPEN Turn the ignition off. Measure the resistance of the (G6) Oil Pressure Signal circuit from the OilPressure Sensor harness connector to the PCM harness connector

Page 1312 of 5267

DODGE RAM SRT-10 2006 Service Repair Manual P0601-PCM INTERNAL CONTROLLER FAILURE For a complete wiring diagramRefer to Section 8W. When Monitored: With the ignition on. Set Condition: Internal checksum for software failed, does not match calcu
